Design Guide | iC7 Series Liquid-cooled System Modules
Table 76: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 50 m (164 ft)
System module
and +AEU1, 2kHz
switching frequency
(1)(1)
System module
and +AEU1, 3kHz
switching frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to air
[kW]
Power
loss to
liquid
[kW]
Power
loss to air
[kW]
Power
loss to air
[kW]
Standby
loss [kW]
iC7-60SLINB5-206AE00F_ IR10L 206 1.56 0.06 1.84 0.06 0.02 0.036
iC7-60SLINB5-245AE00F_ IR10L 245 1.89 0.07 2.21 0.08 0.02 0.036
iC7-60SLINB5-302AE00F_ IR10L 302 2.43 0.09 2.81 0.10 0.04 0.036
iC7-60SLINB5-385AE00F_ IR10L 385 3.39 0.13 3.90 0.14 0.04 0.036
iC7-60SLINB5-416AE00F_ IR10L 416 3.78 0.15 4.33 0.16 0.05 0.036
iC7-60SLINB5-525AE00F_ IR10L 525 3.86 0.12 4.56 0.13 0.04 0.072
iC7-60SLINB5-590AE00F_ IR12L 590 4.41 0.14 5.19 0.15 0.06 0.072
iC7-60SLINB5-650AE00F_ IR12L 650 4.98 0.16 5.91 0.17 0.07 0.072
iC7-60SLINB5-730AE00F_ IR12L 730 5.80 0.18 6.79 0.20 0.08 0.072
iC7-60SLINB5-820AE00F_ IR12L 820 6.83 0.22 7.96 0.24 0.11 0.072
iC7-60SLINB5-1060AE00F_ 2xIR12L 1060 7.79 0.24 9.21 0.27 0.08 0.144
iC7-60SLINB5-1230AE00F_ 2xIR12L 1230 9.30 0.29 10.90 0.32 0.11 0.144
iC7-60SLINB5-1400AE00F_ 2xIR12L 1400 10.91 0.34 12.75 0.38 0.13 0.144
iC7-60SLINB5-1500AE00F_ 2xIR12L 1500 12.13 0.39 14.17 0.43 0.16 0.144
iC7-60SLINB5-1640AE00F_ 2xIR12L 1640 13.65 0.44 15.92 0.48 0.19 0.144
iC7-60SLINB5-1795AE00F_ 3xIR12L 1795 13.60 0.43 16.02 0.48 0.18 0.216
iC7-60SLINB5-2080AE00F_ 3xIR12L 2080 16.32 0.51 19.09 0.57 0.20 0.216
iC7-60SLINB5-2300AE00F_ 3xIR12L 2300 18.71 0.60 21.86 0.66 0.23 0.216
iC7-60SLINB5-2500AE00F_ 3xIR12L 2500 20.90 0.67 24.39 0.73 0.31 0.216
iC7-60SLINB5-2830AE00F_ 4xIR12L 2830 22.31 0.70 26.10 0.78 0.26 0.288
iC7-60SLINB5-3050AE00F_ 4xIR12L 3050 24.73 0.79 28.95 0.87 0.31 0.288
iC7-60SLINB5-3260AE00F_ 4xIR12L 3260 27.15 0.87 31.57 0.95 0.48 0.288
1) System module and the dU/dt Filter in the integration unit
2) DC fuses
10.7.12 Power Losses of INU Modules without Options, Voltage Class B5, Modulator Type 1 –
SVPWM
l The specifications for the values in the table
¢ Inverter module
¢ 380–500 V AC (465–800 V DC)
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 209
