Danfoss iC7 Series Design Guide

The ratings are valid at 1025 V DC-voltage.
10.6.9 Current Ratings for DC/DC Converter 465–800 V DC-bus Voltage, IP00/Open Type
Table 66: Current Ratings for DC/DC Converter 465–800VDC-bus Voltage, IP00/Open Type
DC bus current
DC source current
(1)(1)
DC power,
700...250VDC
source
Model code
I
N-DC
[A] I
N
[A] I
L
[A] I
H
[A] P
L-typ
[kW]
Frame Frame
with
option
+AE__
iC7-60SLDCB5-300AE00F4 307 307 300 225 210...75 DM10L DR10L
iC7-60SLDCB5-360AE00F4 368 368 360 270 252...90 DM10L DR10L
iC7-60SLDCB5-420AE00F4 429 429 420 315 294...105 DM10L DR10L
iC7-60SLDCB5-480AE00F4 490 490 480 360 336...120 DM10L DR10L
iC7-60SLDCB5-570AE00F4 582 582 570 428 399...143 DM10L DR10L
iC7-60SLDCB5-720AE00F4 735 735 720 540 504...180 DM12L DR12L
iC7-60SLDCB5-840AE00F4 858 858 840 630 588...210 DM12L DR12L
iC7-60SLDCB5-960AE00F4 980 980 960 720 672...240 DM12L DR12L
iC7-60SLDCB5-1080E00F4 1103 1103 1080 810 756...270 DM12L DR12L
iC7-60SLDCB5-1200E00F4 1225 1225 1200 900 840...300 DM12L DR12L
iC7-60SLDCB5-1440E00F4 1470 1470 1440 1080 1008...360 2xDM12L 2xDR12L
iC7-60SLDCB5-1680E00F4 1715 1715 1680 1260 1176...420 2xDM12L 2xDR12L
iC7-60SLDCB5-1920E00F4 1960 1960 1920 1440 1344...480 2xDM12L 2xDR12L
iC7-60SLDCB5-2160E00F4 2205 2205 2160 1620 1512...540 2xDM12L 2xDR12L
iC7-60SLDCB5-2400E00F4 2450 2450 2400 1800 1680...600 2xDM12L 2xDR12L
iC7-60SLDCB5-2880E00F4 2940 2940 2880 2160 2016...720 3xDM12L 3xDR12L
iC7-60SLDCB5-3240E00F4 3308 3308 3240 2430 2268...810 3xDM12L 3xDR12L
iC7-60SLDCB5-3600E00F4 3675 3675 3600 2700 2520...900 3xDM12L 3xDR12L
1) Sum of 3 phases.
The ratings are valid at 800 V DC-voltage.
10.7 Power Losses
10.7.1 List of Power Loss Information
The power loss tables for the liquid-cooled system modules can be found with these links.
l 10.7.2 Power Losses of AFE and GC Modules, Voltage Class 07
l 10.7.3 Power Losses of AFE and GC Modules, Voltage Class 07, with +AEZ1 and +AEZ3
l 10.7.4 Power Losses of AFE and GC Modules, Voltage Class B5
l 10.7.5 Power Losses of AFE and GC Modules, Voltage Class B5, with +AEZ1 and +AEZ3
l 10.7.6 Power Losses of INU Modules with +AEU1, Voltage Class 07, Motor Cable Maximum Length 150 m (492 ft)
192 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
