Design Guide | iC7 Series Liquid-cooled System Modules
Table 60: Current Ratings for Active Front-end Module, 380–500 VAC (465–800 VDC) (continued)
AC current DC power, 500 VAC
mains
(2)
Model code
(1)
I
N
[A] I
L
[A] I
H
[A] P
L
[kW] P
H
[kW]
Frame Frame with
option +AEZ1
or +AEZ3
(3)
Input
L Filter
size
[A]
(4)
iC7-60SL3AB5-1230E00F4 1256 1230 922 1044 783 2 x AM12L 2 x AR12L 1640
iC7-60SL3AB5-1325E00F4 1353 1325 993 1125 843 2 x AM12L 2 x AR12L 1640
iC7-60SL3AB5-1500E00F4 1532 1500 1125 1274 955 2 x AM12L 2 x AR12L 1640
iC7-60SL3AB5-1700E00F4 1736 1700 1275 1443 1083 3 x AM12L 3 x AR12L 2 x 1640
iC7-60SL3AB5-1800E00F4 1838 1800 1350 1528 1146 3 x AM12L 3 x AR12L 2 x 1640
iC7-60SL3AB5-2000E00F4 2042 2000 1500 1698 1274 3 x AM12L 3 x AR12L 2 x 1640
iC7-60SL3AB5-2250E00F4 2297 2250 1687 1910 1432 3 x AM12L 3 x AR12L 2 x 1640
iC7-60SL3AB5-2500E00F4 2552 2500 1875 2122 1592 4 x AM12L 4 x AR12L 2 x 1640
iC7-60SL3AB5-2650E00F4 2706 2650 1987 2250 1687 4 x AM12L 4 x AR12L 2 x 1640
iC7-60SL3AB5-2940E00F4 3002 2940 2205 2496 1872 4 x AM12L 4 x AR12L 2 x 1640
1) The hardware has improved transient withstand.
2) cos φ = 1.00, efficiency = 98.0%, values calculated at 742 VDC
3) LC Filter +AEZ1, LCL Filter +AEZ3 (grid side L Filter separate module)
4) Part of LCL Filter, +AEZ3
10.6.4 Current Ratings for GC 525–690 V AC (640–1100 V DC), IP00/Open Type
Table 61: Current Ratings for Grid Converter Module, 525–690 VAC (640–1100 VDC)
AC current
(1)(1)
Power, 690 V AC
mains
Model code
I
N
[A] I
L
[A] I
H
[A] I
S1
[A] I
S2
[A] P
L
[kW] S
L
[kVA]
Frame Frame
with
option
+AEZ1
or
+AEZ3
(2)(2)
Input
L Filter
size
[A]
(3)(3)
iC7-60SLGC07-236AE00F4 241 236 177 354 330 277 283 AM10L AR10L 400
iC7-60SLGC07-300AE00F4 307 300 225 450 420 352 359 AM10L AR10L 400
iC7-60SLGC07-334AE00F4 341 334 250 501 468 392 400 AM10L AR10L 400
iC7-60SLGC07-380AE00F4 388 380 285 570 532 446 455 AM10L AR10L 400
iC7-60SLGC07-425AE00F4 434 425 318 638 595 498 508 AM12L AR12L 1000
iC7-60SLGC07-475AE00F4 485 475 356 712.5 665 557 568 AM12L AR12L 1000
iC7-60SLGC07-530AE00F4 542 530 397 795 742 621 634 AM12L AR12L 1000
iC7-60SLGC07-595AE00F4 608 595 446 892.5 833 697 712 AM12L AR12L 1000
iC7-60SLGC07-670AE00F4 684 670 502 1005 938 785 801 AM12L AR12L 1000
iC7-60SLGC07-760AE00F4 776 760 570 1140 1064 891 909 AM12L AR12L 1000
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 185
