Table 72: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 50 m (164 ft) (continued)
System module
and +AEU1, 2
kHz switching
frequency
(1)(1)
System module
and +AEU1, 3
kHz switching
frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss
[kW]
iC7-60SLIN07-6100E00F_ 8xIR12L 6100 65.04 2.06 77.02 2.41 0.67 1.05
iC7-60SLIN07-6400E00F_ 8xIR12L 6400 68.70 2.17 81.30 2.53 0.77 1.05
1) System module and the dU/dt Filter in the integration unit
2) DC fuses
10.7.8 Power Losses of INU Modules without Options, Voltage Class 07, Modulator Type 1 – SVPWM
l The specifications for the values in the table
¢ Inverter module
¢ 525–690 V AC (640–1100 V DC)
¢ DC voltage 1025 V DC
¢ Switching frequency 2, 3, 4, or 6 kHz
¢ Modulator type 1
Table 73: Power Loss for INU Modules without Options, Modulator Type 1
System
module, 2
kHz switching
frequency
System
module, 3
kHz switching
frequency
System
module, 4
kHz switching
frequency
System
module, 6
kHz switching
frequency
+AKF
X
(1)(1)
Model code Frame Rated
curre
nt
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss
to air
[kW]
iC7-60SLIN07-170AE
00F_
IM10L 170 1.20 0.01 1.51 0.02 1.83 0.02 2.46 0.02 0.01
iC7-60SLIN07-208AE
00F_
IM10L 208 1.49 0.02 1.87 0.02 2.27 0.02 3.17 0.03 0.02
iC7-60SLIN07-261AE
00F_
IM10L 261 1.95 0.02 2.46 0.02 2.99 0.03 - - 0.02
iC7-60SLIN07-325AE
00F_
IM10L 325 2.57 0.03 3.23 0.03 - - - - 0.04
iC7-60SLIN07-365AE
00F_
IM10L 365 3.00 0.03 - - - - - - 0.04
202 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
