Design Guide | iC7 Series Liquid-cooled System Modules
Table 73: Power Loss for INU Modules without Options, Modulator Type 1 (continued)
System
module, 2
kHz switching
frequency
System
module, 3
kHz switching
frequency
System
module, 4
kHz switching
frequency
System
module, 6
kHz switching
frequency
+AKF
X
(1)(1)
Model code Frame Rated
curre
nt
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss
to air
[kW]
iC7-60SLIN07-416AE
00F_
IM10L 416 3.60 0.04 - - - - - - 0.05
iC7-60SLIN07-465AE
00F_
IM12L 465 3.40 0.03 4.25 0.04 5.15 0.05 - - 0.03
iC7-60SLIN07-525AE
00F_
IM12L 525 3.93 0.04 4.91 0.05 5.97 0.06 - - 0.04
iC7-60SLIN07-590AE
00F_
IM12L 590 4.54 0.05 5.80 0.06 6.94 0.07 - - 0.06
iC7-60SLIN07-650AE
00F_
IM12L 650 5.14 0.05 6.47 0.06 - - - - 0.07
iC7-60SLIN07-730AE
00F_
IM12L 730 6.00 0.06 - - - - - - 0.08
iC7-60SLIN07-820AE
00F_
IM12L 820 7.05 0.07 - - - - - - 0.11
iC7-60SLIN07-945AE
00F_
2xIM12L 945 6.93 0.07 9.30 0.09 11.40 0.11 - - 0.05
iC7-60SLIN07-1060E
00F_
2xIM12L 1060 7.95 0.08 9.83 0.10 11.95 0.12 - - 0.08
iC7-60SLIN07-1230E
00F_
2xIM12L 1230 9.57 0.10 12.02 0.12 - - - - 0.11
iC7-60SLIN07-1400E
00F_
2xIM12L 1400 11.33 0.11 14.30 0.14 - - - - 0.13
iC7-60SLIN07-1500E
00F_
2xIM12L 1500 12.44 0.13 - - - - - - 0.16
iC7-60SLIN07-1640E
00F_
2xIM12L 1640 14.10 0.14 - - - - - - 0.19
iC7-60SLIN07-1795E
00F_
3xIM12L 1795 13.86 0.14 16.80 0.17 21.00 0.21 - - 0.18
iC7-60SLIN07-2080E
00F_
3xIM12L 2080 16.79 0.17 21.14 0.21 - - - - 0.20
iC7-60SLIN07-2300E
00F_
3xIM12L 2300 19.24 0.19 - - - - - - 0.23
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 203
