Danfoss iC7 Series Design Guide

Table 53: DC Fuses for AFE or GC 640–1200 V DC, IP00/Open Type (continued)
Model code
(1)(1)
Frame Rated
current
I
L
[A]
Number
of fuses
Fuse
size
Part number Fuse U
n
[V]
Fuse I
n
[A]
I
cp, mr
[A]
iC7-60SL3A0x-5400E00Fx 5400
iC7-60SL3A0x-5750E00Fx
8 x Ax12L
5750
32 73 PC73UD12C900TF 1200 900 10200
1) For example, iC7-60SL3A07-236AE00F4
10.5.4 DC Fuses for INU 640–1200 V DC, IP00/Open Type
Table 54: DC Fuses for INU 640–1200 V DC, IP00/Open Type
Model code
(1)(1)
Frame Rated
current
I
L
[A]
Number
of fuses
Fuse
size
Part number Fuse U
n
[V]
Fuse I
n
[A]
I
cp, mr
[A]
iC7-60SLIN0x-170AE00Fx 170
iC7-60SLIN0x-206AE00Fx
(2)(2)
206
iC7-60SLIN0x-208AE00Fx 208
PC73UD13C630TF 630 5900
iC7-60SLIN0x-245AE00Fx
(2)
245
iC7-60SLIN0x-261AE00Fx 261
iC7-60SLIN0x-302AE00Fx
(2)
302
iC7-60SLIN0x-325AE00Fx 325
PC73UD13C800TF
1250
800 8900
iC7-60SLIN0x-365AE00Fx 365
iC7-60SLIN0x-385AE00Fx
(2)
385
iC7-60SLIN0x-416AE00Fx
Ix10L
416
2 73
PC73UD12C900TF 1200 900 10200
iC7-60SLIN0x-465AE00Fx 465
iC7-60SLIN0x-525AE00Fx 525
iC7-60SLIN0x-590AE00Fx 590
iC7-60SLIN0x-650AE00Fx 650
PC73UD13C800TF 1250 800 8900
iC7-60SLIN0x-730AE00Fx 730
iC7-60SLIN0x-820AE00Fx
Ix12L
820
4 73
PC73UD12C900TF 1200 900 10200
iC7-60SLIN0x-945AE00Fx 945
iC7-60SLIN0x-1060E00Fx 1060
iC7-60SLIN0x-1230E00Fx 1230
PC73UD13C800TF 1250 800 8900
iC7-60SLIN0x-1400E00Fx 1400
iC7-60SLIN0x-1500E00Fx 1500
iC7-60SLIN0x-1640E00Fx
2 x Ix12L
1640
8 73
PC73UD12C900TF 1200 900 10200
178 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
