Design Guide | iC7 Series Liquid-cooled System Modules
6.4.2 Heat Exchanger
The heat exchanging equipment can be located outside the electrical room in which the AC drives are. The connections between these
two are made on site. To minimize the pressure drops, the piping must be made as short and straight as possible. It is also recommended
to install a regulating valve that is equipped with a flow rate measurement point. This makes it possible to measure and regulate the
coolant circulation in the commissioning phase.
The highest point of the piping must be equipped with either an automatic or a manual venting device. The material of the piping must
comply with at least AISI 304 (and AISI 316 is recommended). Before connecting the pipes, clean the bores thoroughly. If cleaning with
water is not possible, use pressured air to remove all loose particles and dust.
6.4.3 Flow Rate of the Coolant
Table 8: Liquid-cooled System Modules and Integrated Filters
Product type Frame Nominal flow
rate with
water [l/min]
Nominal flow
rate with
30% glycol [l/
min]
Nominal flow
rate with
50% glycol [l/
min]
Maximum
flow rate [l/
min]
Liquid
volume per
element [l]
GC/AFE/INU module AM10L/IM10L 11.0 14.5 16.5 18.0 0.55
GC/AFE/INU module AM12L/IM12L 22.0 29.0 33.0 36.0 1.10
AFE/GC with LC Filter for AFE
(+AEZ1)
AR10L 19 25 29 30 1.70
AFE/GC with LC Filter for AFE
(+AEZ1)
AR12L 34 44 51 54 3.25
INU with dU/dt Filter (+AEU1) IR10L 26 33 38 41 1.68
INU with dU/dt and CM Filter
(+AEU1, +AEU2)
IR10L 26 33 38 41 1.68
INU without filters (+AE10) IR10L 12 16 18 19 1.50
INU with dU/dt Filter (+AEU1) IR12L 37 48 56 59 3.34
INU without filters (+AE10) IR12L 25 33 38 40 3.00
INU with Sine-wave Filter
(+AES1)
IR10L 19 25 29 30 1.70
INU with Sine-wave Filter
(+AES1)
IR12L 34 44 51 54 3.25
DC/DC converter with DC Filter
(+AED1)
DR10L 18 23 27 28 1.70
DC/DC converter with DC Filter
(+AED1)
DR12L 34 44 51 54 3.25
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 41
