Danfoss iC7 Series Design Guide

Design Guide | iC7 Series Liquid-cooled System Modules
10.4.3 Internal Cable Sizes for AFE and GC Modules, 525–690 V AC
Table 46: Bolt Sizes for the AFE and GC Modules
Frame
(1)
Bolt size for internal cable or busbar Number of grounding terminals/bolt size
Ax10L M10 1/M8
Ax12L M10 1/M8
2 x Ax12L M10 2/M8
3 x Ax12L M10 3/M8
4 x Ax12L M10 4/M8
5 x Ax12L M10 5/M8
6 x Ax12L M10 6/M8
7 x Ax12L M10 7/M8
8 x Ax12L M10 8/M8
1) AM10L, AR10L, AM12L, or AR12L
10.4.4 Field Cable Sizes for INU Module, 525–690 V AC
Table 47: Field Cable Sizes for INU Module, 525–690 V AC
Model code
Frame
(1)
I
N
[A] Motor cable
Cu [mm
2
]
Motor cable
Al [mm
2
]
Terminal
max. cable
size
Number of
grounding
terminals/
bolt size
Max.
number of
cables/ bolt
size
iC7-60SLIN07-170E00Fx 215 3x120+70 3x185+57 300 Cu/Al 1/M8 2/M10
iC7-60SLIN07-261E00Fx 270 3x185+95 2x(3x95+29) 300 Cu/Al 1/M8 2/M10
iC7-60SLIN07-325E00Fx 335 3x240+120 2x(3x120+41) 300 Cu/Al 1/M8 2/M10
iC7-60SLIN07-365E00Fx 375 2x(3x95+50) 2x(3x150+41) 300 Cu/Al 1/M8 2/M10
iC7-60SLIN07-416E00Fx
Ix10L
425 2x(3x120+70) 2x(3x185+57) 300 Cu/Al 1/M8 2/M10
iC7-60SLIN07-465E00Fx 475 2x(3x150+70) 2x(3x240+72) 300 Cu/Al 1/M8 4/M10
iC7-60SLIN07-525E00Fx 535 2x(3x185+95) 3x(3x150+41) 300 Cu/Al 1/M8 4/M10
iC7-60SLIN07-590E00Fx 605 2x(3x240+12
0)
3x(3x185+57) 300 Cu/Al 1/M8 4/M10
iC7-60SLIN07-650E00Fx 665 2x(3x240+12
0)
3x(3x185+57) 300 Cu/Al 1/M8 4/M10
iC7-60SLIN07-730E00Fx 745 3x(3x150+70) 4x(3x150+41) 300 Cu/Al 1/M8 4/M10
iC7-60SLIN07-820E00Fx
Ix12L
840 4x(3x120+70) 4x(3x185+57) 300 Cu/Al 1/M8 4/M10
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 169
