Table 67: Power Loss for AFE and GC Modules (continued)
System module
+AKFX
(1)(1)
Model code Frame Rated
current
I
L(1/5)
[A]
Power loss
to liquid
[kW]
Power loss
to air [kW]
Power loss
to air [kW]
Standby
loss [kW]
iC7-60SL3A07-1800E00F_ 3xAM12L 1800 26.67 0.27 0.09 0.39
iC7-60SL3A07-2000E00F_ 3xAM12L 2000 30.71 0.31 0.14 0.39
iC7-60SL3A07-2250E00F_ 3xAM12L 2250 36.25 0.37 0.20 0.39
iC7-60SL3A07-2500E00F_ 4xAM12L 2500 37.52 0.38 0.17 0.52
iC7-60SL3A07-2650E00F_ 4xAM12L 2650 40.60 0.41 0.19 0.52
iC7-60SL3A07-2940E00F_ 4xAM12L 2940 46.95 0.47 0.28 0.52
iC7-60SL3A07-3120E00F_ 5xAM12L 3120 46.80 0.47 0.18 0.66
iC7-60SL3A07-3600E00F_ 5xAM12L 3600 56.99 0.58 0.33 0.66
iC7-60SL3A07-3900E00F_ 6xAM12L 3900 59.34 0.60 0.25 0.79
iC7-60SL3A07-4320E00F_ 6xAM12L 4320 68.38 0.69 0.40 0.79
iC7-60SL3A07-4750E00F_ 7xAM12L 4750 73.43 0.74 0.34 0.92
iC7-60SL3A07-5040E00F_ 7xAM12L 5040 79.78 0.81 0.46 0.92
iC7-60SL3A07-5400E00F_ 8xAM12L 5400 83.30 0.84 0.38 1.05
iC7-60SL3A07-5750E00F_ 8xAM12L 5750 90.97 0.92 0.53 1.05
1) DC fuses
10.7.3 Power Losses of AFE and GC Modules, Voltage Class 07, with +AEZ1 and +AEZ3
l The specifications for the values in the table
¢ AFE or GC module
¢ 525–690 V AC (640–1100 V DC)
¢ DC voltage 1025 V DC
¢ Modulator type 4
n The default modulator type for grid converters is type 5, which results in slightly lower losses than given in the table.
¢ Option +AEZ1 or +AEZ3
194 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
