Danfoss iC7 Series Design Guide

6.4.6.3 Inlet and Outlet Connectors of System Modules
 NOTICE
INCORRECT INLET AND OUTLET CONNECTIONS IN THE COOLING SYSTEM
If inlet and outlet connectors are connected incorrectly, the cooling does not work as expected. Incorrect cooling can damage the
product.
l Make the connections carefully.
e30bl377.10
1
1
Figure 47: Inlet Connectors of IM10L (left) and IM12L (right)
1 Inlet connectors
e30bl378.10
1
Figure 48: Outlet Connectors of IM10L (left) and IM12L (right)
1 Outlet connectors
54 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
