Danfoss iC7 Series Design Guide

Table 71: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 150 m (492 ft) (continued)
System module
and +AEU1, 2
kHz switching
frequency
(1)(1)
System module
and +AEU1, 3
kHz switching
frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss
[kW]
iC7-60SLIN07-4400E00F_ 6xIR12L 4400 52.44 1.76 62.02 2.09 0.54 0.79
iC7-60SLIN07-4850E00F_ 6xIR12L 4850 59.59 2.04 72.64 2.50 0.58 0.79
iC7-60SLIN07-5300E00F_ 7xIR12L 5300 64.60 2.24 79.58 2.76 0.59 0.92
iC7-60SLIN07-5600E00F_ 7xIR12L 5600 69.29 2.37 83.86 2.89 0.67 0.92
iC7-60SLIN07-6100E00F_ 8xIR12L 6100 75.02 2.58 91.56 3.18 0.67 1.05
iC7-60SLIN07-6400E00F_ 8xIR12L 6400 78.67 2.70 95.85 3.30 0.77 1.05
1) System module and the dU/dt Filter in the integration unit
2) DC fuses
10.7.7 Power Losses of INU Modules with +AEU1, Voltage Class 07, Motor Cable Maximum Length
50 m (164 ft)
l The specifications for the values in the table
¢ Inverter module
¢ 525–690 V AC (640–1100 V DC)
¢ Option +AEU1
¢ Switching frequency 2 kHz or 3 kHz
¢ Modulator type 2
¢ Motor cable length a maximum of 50 m (164 ft)
Table 72: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 50 m (164 ft)
System module
and +AEU1, 2
kHz switching
frequency
(1)(1)
System module
and +AEU1, 3
kHz switching
frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss
[kW]
iC7-60SLIN07-170AE00F_ IR10L 170 1.83 0.07 2.27 0.08 0.01 0.07
iC7-60SLIN07-208AE00F_ IR10L 208 2.17 0.08 2.65 0.10 0.02 0.07
iC7-60SLIN07-261AE00F_ IR10L 261 2.73 0.10 3.24 0.11 0.02 0.07
iC7-60SLIN07-325AE00F_ IR10L 325 3.46 0.13 4.05 0.14 0.04 0.07
200 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
