Design Guide | iC7 Series Liquid-cooled System Modules
Table 72: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 50 m (164 ft) (continued)
System module
and +AEU1, 2
kHz switching
frequency
(1)(1)
System module
and +AEU1, 3
kHz switching
frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss
[kW]
iC7-60SLIN07-365AE00F_ IR10L 365 4.17 0.15 4.75 0.17 0.04 0.07
iC7-60SLIN07-416AE00F_ IR10L 416 4.82 0.18 5.56 0.20 0.05 0.07
iC7-60SLIN07-465AE00F_ IR12L 465 4.64 0.15 5.69 0.19 0.03 0.13
iC7-60SLIN07-525AE00F_ IR12L 525 5.19 0.17 6.31 0.20 0.04 0.13
iC7-60SLIN07-590AE00F_ IR12L 590 5.92 0.19 7.05 0.22 0.06 0.13
iC7-60SLIN07-650AE00F_ IR12L 650 6.50 0.20 7.77 0.24 0.07 0.13
iC7-60SLIN07-730AE00F_ IR12L 730 7.75 0.24 9.00 0.28 0.08 0.13
iC7-60SLIN07-820AE00F_ IR12L 820 8.99 0.28 10.46 0.33 0.11 0.13
iC7-60SLIN07-945AE00F_ 2xIR12L 945 9.84 0.31 11.53 0.38 0.05 0.26
iC7-60SLIN07-1060E00F_ 2xIR12L 1060 10.42 0.34 12.75 0.41 0.08 0.26
iC7-60SLIN07-1230E00F_ 2xIR12L 1230 12.23 0.39 14.69 0.46 0.11 0.26
iC7-60SLIN07-1400E00F_ 2xIR12L 1400 14.15 0.44 16.81 0.52 0.13 0.26
iC7-60SLIN07-1500E00F_ 2xIR12L 1500 15.93 0.51 18.92 0.60 0.16 0.26
iC7-60SLIN07-1640E00F_ 2xIR12L 1640 17.72 0.56 20.92 0.65 0.19 0.26
iC7-60SLIN07-1795E00F_ 3xIR12L 1795 17.83 0.58 22.01 0.70 0.18 0.39
iC7-60SLIN07-2080E00F_ 3xIR12L 2080 21.39 0.68 25.55 0.80 0.20 0.39
iC7-60SLIN07-2300E00F_ 3xIR12L 2300 24.43 0.78 29.05 0.91 0.23 0.39
iC7-60SLIN07-2500E00F_ 3xIR12L 2500 27.12 0.86 31.99 0.99 0.31 0.39
iC7-60SLIN07-2830E00F_ 4xIR12L 2830 29.14 0.92 34.79 1.08 0.26 0.52
iC7-60SLIN07-3050E00F_ 4xIR12L 3050 32.53 1.03 38.52 1.21 0.31 0.52
iC7-60SLIN07-3260E00F_ 4xIR12L 3260 35.34 1.11 41.53 1.29 0.48 0.52
iC7-60SLIN07-3500E00F_ 5xIR12L 3500 36.06 1.14 43.00 1.34 0.33 0.66
iC7-60SLIN07-4035E00F_ 5xIR12L 4035 43.38 1.37 51.31 1.60 0.51 0.66
iC7-60SLIN07-4400E00F_ 6xIR12L 4400 46.57 1.45 54.27 1.69 0.54 0.79
iC7-60SLIN07-4850E00F_ 6xIR12L 4850 52.10 1.65 61.73 1.92 0.58 0.79
iC7-60SLIN07-5300E00F_ 7xIR12L 5300 55.86 1.78 66.85 2.09 0.59 0.92
iC7-60SLIN07-5600E00F_ 7xIR12L 5600 60.56 1.91 71.13 2.22 0.67 0.92
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 201
