Design Guide | iC7 Series Liquid-cooled System Modules
10.3.2 Wiring Diagram, AFE/GC, AR12L
DC-
DC+
L3
L2
L1
DC-
DC+
L3
L2
L1
L1
L1'
L2'
L2
L3
L3'
L1
L1'
L2'L2
L3
L3'
AFE
AFE
DC+
DC-
DC+
DC-
L2
L1
L3
PE
PE
1
2
3
4
5
6
7
8
e30bg428.10
1 L Filter, grid side, loose option 2 AFE/GC module AR12L
3 Input terminals 4 AC fuses
5 LCL Filter choke, drive side 6 DC fuses, loose option
7 LCL Filter capacitors 8 Supply
Figure 159: Wiring Diagram, AR12L
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 157
