Danfoss iC7 Series Design Guide

Table 59: Current Ratings for Active Front-end Module, 525–690 VAC (640–1100 VDC) (continued)
AC current DC power, 690 VAC
mains
(1)(1)
Model code
I
N
[A] I
L
[A] I
H
[A] P
L
[kW] P
H
[kW]
Frame Frame with
option +AEZ1
or +AEZ3
(2)(2)
Input
L Filter
size
[A]
(3)(3)
iC7-60SL3A07-2650E00F4 2706 2650 1987 3104 2328 4 x AM12L 4 x AR12L 2 x 1640
iC7-60SL3A07-2940E00F4 3002 2940 2205 3444 2583 4 x AM12L 4 x AR12L 2 x 1640
iC7-60SL3A07-3120E00F4 3185 3120 2340 3655 2741 5 x AM12L 5 x AR12L 3 x 1640
iC7-60SL3A07-3600E00F4 3675 3600 2700 4217 3163 5 x AM12L 5 x AR12L 3 x 1640
iC7-60SL3A07-3900E00F4 3982 3900 2925 4568 3426 6 x AM12L 6 x AR12L 3 x 1640
iC7-60SL3A07-4320E00F4 4410 4320 3240 5060 3795 6 x AM12L 6 x AR12L 3 x 1640
iC7-60SL3A07-4750E00F4 4849 4750 3562 5564 4172 7 x AM12L 7 x AR12L 4 x 1640
iC7-60SL3A07-5040E00F4 5145 5040 3780 5903 4428 7 x AM12L 7 x AR12L 4 x 1640
iC7-60SL3A07-5400E00F4 5513 5400 4050 6325 4744 8 x AM12L 8 x AR12L 4 x 1640
iC7-60SL3A07-5750E00F4 5870 5750 4312 6735 5051 8 x AM12L 8 x AR12L 4 x 1640
1) cos φ = 1.00, efficiency = 98.0%, values calculated at 1025 VDC
2) LC Filter +AEZ1, LCL Filter +AEZ3 (grid side L Filter separate module)
3) Part of LCL Filter, +AEZ3
10.6.3 Current Ratings for AFE 380–500 V AC (465–800 V DC), IP00/Open Type
Table 60: Current Ratings for Active Front-end Module, 380–500 VAC (465–800 VDC)
AC current DC power, 500 VAC
mains
(2)
Model code
(1)
I
N
[A] I
L
[A] I
H
[A] P
L
[kW] P
H
[kW]
Frame Frame with
option +AEZ1
or +AEZ3
(3)
Input
L Filter
size
[A]
(4)
iC7-60SL3AB5-261AE00F4 267 261 196 222 167 AM10L AR10L 400
iC7-60SL3AB5-325AE00F4 332 325 244 276 208 AM10L AR10L 400
iC7-60SL3AB5-380AE00F4 388 380 285 323 242 AM10L AR10L 400
iC7-60SL3AB5-425AE00F4 434 425 318 361 270 AM12L AR12L 1000
iC7-60SL3AB5-475AE00F4 485 475 356 404 303 AM12L AR12L 1000
iC7-60SL3AB5-530AE00F4 542 530 397 450 337 AM12L AR12L 1000
iC7-60SL3AB5-595AE00F4 608 595 446 505 379 AM12L AR12L 1000
iC7-60SL3AB5-670AE00F4 684 670 502 569 427 AM12L AR12L 1000
iC7-60SL3AB5-760AE00F4 776 760 570 646 484 AM12L AR12L 1000
iC7-60SL3AB5-850AE00F4 868 850 637 722 541 2 x AM12L 2 x AR12L 1640
iC7-60SL3AB5-945AE00F4 965 945 708 803 601 2 x AM12L 2 x AR12L 1640
iC7-60SL3AB5-1040E00F4 1062 1040 780 883 662 2 x AM12L 2 x AR12L 1640
184 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
