Design Guide | iC7 Series Liquid-cooled System Modules
Table 6: Description of the Model Code (continued)
Code Description
07 Voltage rating
07 = 525–690 V AC (640–1100 V DC)
B5 = 380–500 V AC
-300A Current rating (I
L(1/5)
)
-03A0 = 3 A
-300A = 300 A
-3000 = 3000 A
E00 Protection rating
E00 = IP00/Open type
F4 EMC level
F3 = C3 industry environment
F4 = C4 system component
+XXXX Options
See separate list.
4.8 Labels on the Products
4.8.1 Labels on the System Module
To provide information about the product and the system modules, several labels are placed in the front of the modules.
l Product label
¢ Includes the model code and other information about the product. See 4.7 Description of the Model Code.
¢ See 4.8.3 Product Label.
¢ When the product includes several system modules, the product label is only placed on the first module on the left-hand side of
the lineup.
¢ The product label is on a detachable plate. If the module is replaced, remove the label plate and mount it on the new module.
l Power module label
¢ Includes information about the system module.
¢ The information on the label is specific to each system module.
¢ Includes the serial number of the product to which the system module belongs.
l Approvals label
¢ List of approvals for the product.
l Service label
¢ Label for service-related information.
l Product modified label
¢ List of changes done to the module.
¢ See 9.3 Using the Product Modified Label.
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 23
