Danfoss iC7 Series Design Guide

Table 63: Current Ratings for Inverter Module 525–690 VAC (640–1100 VDC) (continued)
AC current Motor output power,
690 VAC
(1)(1)
Model code
I
N
[A] I
L
[A] I
H
[A] I
peak
[A] P
L
[kW] P
H
[kW]
Frame Frame
with
option
+AExx
iC7-60SLIN07-5300E00F4 5411 5300 3975 7950 5000 3700 7 x IM12L 7 x IR12L
iC7-60SLIN07-5600E00F4 5717 5600 4200 8400 5300 4000 7 x IM12L 7 x IR12L
iC7-60SLIN07-6100E00F4 6227 6100 4575 9150 5700 4300 8 x IM12L 8 x IR12L
iC7-60SLIN07-6400E00F4 6534 6400 4800 9600 6000 4600 8 x IM12L 8 x IR12L
1) efficiency = 98.5%
10.6.7 Current Ratings for INU 380–500 V AC (465–800 V DC), IP00/Open Type
Table 64: Current Ratings for Inverter Module, 380–500 VAC (465–800 VDC)
AC current Motor output power,
500 VAC
(2)(2)
Model code
(1)(1)
I
N
[A] I
L
[A] I
H
[A] I
peak
[A] P
L
[kW] P
H
[kW]
Frame Frame
with
option
+AExx
iC7-60SLINB5-206AE00F4 211 206 155 310 132 90 IM10L IR10L
iC7-60SLINB5-245AE00F4 251 245 184 368 160 110 IM10L IR10L
iC7-60SLINB5-302AE00F4 309 302 227 454 200 132 IM10L IR10L
iC7-60SLINB5-385AE00F4 394 385 289 578 250 160 IM10L IR10L
iC7-60SLINB5-416AE00F4 425 416 312 624 270 200 IM10L IR10L
iC7-60SLINB5-525AE00F4 536 525 393 786 355 250 IM12L IR12L
iC7-60SLINB5-590AE00F4 603 590 442 884 400 250 IM12L IR12L
iC7-60SLINB5-650AE00F4 672 650 487 974 400 315 IM12L IR12L
iC7-60SLINB5-730AE00F4 746 730 547 1094 500 355 IM12L IR12L
iC7-60SLINB5-820AE00F4 838 820 615 1230 560 400 IM12L IR12L
iC7-60SLINB5-1060E00F4 1083 1060 795 1590 630 500 2 x IM12L 2 x IR12L
iC7-60SLINB5-1230E00F4 1256 1230 922 1844 800 630 2 x IM12L 2 x IR12L
iC7-60SLINB5-1400E00F4 1430 1400 1050 2100 900 710 2 x IM12L 2 x IR12L
iC7-60SLINB5-1500E00F4 1532 1500 1125 2250 1000 710 2 x IM12L 2 x IR12L
iC7-60SLINB5-1640E00F4 1675 1640 1230 2460 1100 800 2 x IM12L 2 x IR12L
iC7-60SLINB5-1795E00F4 1833 1795 1346 2692 1200 900 3 x IM12L 3 x IR12L
iC7-60SLINB5-2080E00F4 2124 2080 1560 3120 1400 1000 3 x IM12L 3 x IR12L
iC7-60SLINB5-2300E00F4 2348 2300 1725 3450 1500 1100 3 x IM12L 3 x IR12L
iC7-60SLINB5-2500E00F4 2552 2500 1875 3750 1700 1200 3 x IM12L 3 x IR12L
190 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
