Danfoss iC7 Series Design Guide

4.3 Contents of the Delivery
The contents of the shipment of system modules
l Control unit with ordered control options
l Star coupler board for frames IM12L, AM12L, DM12L, IR12L, AR12L, and DR12L when the product consists of 2–16 power units
l Power unit
l Optical fiber cable
l One or two accessories bags for each power unit
l Other parts based on selected options
l Safety instructions
4.4 Description of the Frame Designation
A frame designation is used to refer to different types of iC7 Series system modules. The frame designation describes the function,
mechanical variant, size, and cooling method of the system module.
The frame designation can have this format, for example:
IM10L
Table 3: Description of the Frame Designation
Code Description
I Function
I = Inverter
A = Active front-end/Grid converter
D = DC/DC converter
M Mechanical variant
M = System module
R = System module with integration unit
10 Size
10 or 12
L Cooling method
L = Liquid-cooled
4.5 Weights
The weights in Table 4 include the system module, the integration unit and the filters.
Table 4: Weights of the Liquid-cooled System Modules
Product Weight [kg] Weight [lb]
Inverter module, AFE/GC module, or DC/DC converter module, IM10L, AM10L, DM10L 41 90
Inverter module + integration unit (no filter +AE10), IR10L 73 161
Inverter module + integration unit (dU/dt Filter +AEU1), IR10L 106 234
Inverter module + integration unit (dU/dt+CM Filter +AEU2), IR10L 115 254
Inverter module + integration unit (Sine-wave Filter +AES1), IR10L 138 304
20 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
