10.2.18 Dimensions of the Control Unit
79.3
(3.12)
297
(11.69)
234
(9.21)
83.4
(3.28)
e30bi572.11
Figure 144: Dimensions of the Control Unit in mm (in), Example Configuration
144 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
