10.3.3 Wiring Diagram, INU, IR10L
DC-
DC+
W
V
U
U'
V'
W'
U
V
W
DC+
DC-
PE
1
2
3
7
6
8
e30bg429.10
4
5
1 DC fuses, loose option 2 Inverter module IR10L
3 Damping resistors 4 Damping resistor
5 Common-mode Filter 6 Output terminals
7 dU/dt Filter capacitors 8 dU/dt Filter choke
Figure 160: Wiring Diagram, IR10L
158 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
