Danfoss iC7 Series Design Guide

Table 79: Power Loss for DC/DC Converter Modules (continued)
Frame System module System module with
+AED1
(1)
Product
code
System
module
System
module
with
+AED1
Nominal
current I
L
[A]
Power
loss to
liquid
[kW]
Power
loss to air
[kW]
Power
loss to
liquid
[kW]
Power
loss to air
[kW]
DC fuses
+AKFF
(2)
[kW]
Standby
loss [kW]
07-720A DM12L DR12L 720 4.79 0.05 5.80 0.16 0.24 0.13
07-840A DM12L DR12L 840 5.67 0.06 6.98 0.20 0.31 0.13
07-960A DM12L DR12L 960 6.61 0.07 8.30 0.26 0.33 0.13
07-1080 DM12L DR12L 1080 7.63 0.08 9.76 0.31 0.34 0.13
07-1200 DM12L DR12L 1200 8.73 0.09 11.36 0.38 0.45 0.13
07-1440 2xDM12L 2xDR12L 1440 9.58 0.10 11.59 0.32 0.46 0.26
07-1680 2xDM12L 2xDR12L 1680 11.33 0.11 13.97 0.41 0.60 0.26
07-1920 2xDM12L 2xDR12L 1920 13.22 0.13 16.61 0.51 0.68 0.26
07-2160 2xDM12L 2xDR12L 2160 15.25 0.15 19.53 0.63 0.69 0.26
07-2400 2xDM12L 2xDR12L 2400 17.46 0.18 22.73 0.76 0.81 0.26
07-2880 3xDM12L 3xDR12L 2880 19.82 0.20 24.91 0.77 1.02 0.39
07-3240 3xDM12L 3xDR12L 3240 22.88 0.23 29.29 0.94 1.03 0.39
07-3600 3xDM12L 3xDR12L 3600 26.19 0.27 34.09 1.14 1.21 0.39
1) +AED1 = LC Filter
2) +AKFF = DC bus fuses and source fuses
10.7.15 Power Losses of DC/DC Converter Modules, Voltage Class B5
l The specifications for the values in the table
¢ DC/DC converter module
¢ DC voltage 594 V DC
¢ Default switching frequency
¢ Power losses at rated low overload current I
L
, 50% duty cycle
Table 80: Power Loss for DC/DC Converter Modules
Frame Power loss [kW]Product code
System
module
System
module with
+AED1
Nominal
current I
L
[A]
System
module
System
module with
+AED1
(1)
DC fuses
+AKFF
(2)
Standby loss
[kW]
B5-300A DM10L DR10L 300 1.64 1.83 0.08 0.04
B5-360A DM10L DR10L 360 1.95 2.19 0.11 0.04
B5-420A DM10L DR10L 420 2.28 2.58 0.13 0.04
214 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
