Design Guide | iC7 Series Liquid-cooled System Modules
Table 80: Power Loss for DC/DC Converter Modules (continued)
Frame Power loss [kW]Product code
System
module
System
module with
+AED1
Nominal
current I
L
[A]
System
module
System
module with
+AED1
(1)
DC fuses
+AKFF
(2)
Standby loss
[kW]
B5-480A DM10L DR10L 480 2.63 3.00 0.14 0.04
B5-570A DM10L DR10L 570 3.20 3.70 0.19 0.04
B5-720A DM12L DR12L 720 3.51 4.19 0.24 0.07
B5-840A DM12L DR12L 840 4.11 5.03 0.31 0.07
B5-960A DM12L DR12L 960 4.74 5.94 0.33 0.07
B5-1080 DM12L DR12L 1080 5.42 6.95 0.34 0.07
B5-1200 DM12L DR12L 1200 6.13 8.04 0.45 0.07
B5-1440 2xDM12L 2xDR12L 1440 7.02 8.38 0.46 0.14
B5-1680 2xDM12L 2xDR12L 1680 8.22 10.06 0.60 0.14
B5-1920 2xDM12L 2xDR12L 1920 9.49 11.89 0.68 0.14
B5-2160 2xDM12L 2xDR12L 2160 10.83 13.89 0.69 0.14
B5-2400 2xDM12L 2xDR12L 2400 12.26 16.08 0.81 0.14
B5-2880 3xDM12L 3xDR12L 2880 14.23 17.83 1.02 0.22
B5-3240 3xDM12L 3xDR12L 3240 16.24 20.84 1.03 0.22
B5-3600 3xDM12L 3xDR12L 3600 18.38 24.12 1.21 0.22
1) +AED1 = LC Filter
2) +AKFF = DC bus fuses and source fuses
