Table 70: Power Loss for AFE and GC Modules with Options +AEZ1 and +AEZ3 (continued)
System module and
+AEZ1
(1)(1)
System module and
+AEZ3
(2)(2)
+AKFX
(3)(3)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss,
system
module
and
+AEZ1
[kW]
iC7-60SL3AB5-475A AR12L 475 5.11 0.23 5.24 0.32 0.02 0.07
iC7-60SL3AB5-530A AR12L 530 5.84 0.29 6.01 0.40 0.03 0.07
iC7-60SL3AB5-595A AR12L 595 6.75 0.34 6.95 0.47 0.04 0.07
iC7-60SL3AB5-670A AR12L 670 7.95 0.45 8.21 0.63 0.05 0.07
iC7-60SL3AB5-760A AR12L 760 9.48 0.54 9.81 0.76 0.07 0.07
iC7-60SL3AB5-850A 2xAR12L 850 8.94 0.37 9.26 0.59 0.02 0.15
iC7-60SL3AB5-945A 2xAR12L 945 10.16 0.46 10.57 0.73 0.04 0.15
iC7-60SL3AB5-1040 2xAR12L 1040 11.41 0.57 11.91 0.91 0.04 0.15
iC7-60SL3AB5-1230 2xAR12L 1230 14.12 0.75 14.81 1.21 0.07 0.15
iC7-60SL3AB5-1325 2xAR12L 1325 15.65 0.86 16.47 1.41 0.1 0.15
iC7-60SL3AB5-1500 2xAR12L 1500 18.60 1.08 19.67 1.79 0.13 0.15
iC7-60SL3AB5-1700 3xAR12L 1700 19.05 0.94 19.69 1.37 0.11 0.22
iC7-60SL3AB5-1800 3xAR12L 1800 20.47 1.04 21.18 1.51 0.09 0.22
iC7-60SL3AB5-2000 3xAR12L 2000 23.67 1.30 24.57 1.90 0.14 0.22
iC7-60SL3AB5-2250 3xAR12L 2250 27.90 1.60 29.05 2.37 0.2 0.22
iC7-60SL3AB5-2500 4xAR12L 2500 28.88 1.52 30.31 2.47 0.17 0.30
iC7-60SL3AB5-2650 4xAR12L 2650 31.30 1.68 32.94 2.78 0.19 0.30
iC7-60SL3AB5-2940 4xAR12L 2940 36.16 2.03 38.22 3.40 0.28 0.30
1) System module and the LC Filter in the integration unit
2) System module and the LC Filter in the integration unit and the L Filter
3) DC fuses
10.7.6 Power Losses of INU Modules with +AEU1, Voltage Class 07, Motor Cable Maximum Length
150 m (492 ft)
l The specifications for the values in the table
¢ Inverter module
¢ 525–690 V AC (640–1100 V DC)
¢ Option +AEU1
¢ Switching frequency 2 kHz or 3 kHz
¢ Modulator type 2
¢ Motor cable length a maximum of 150 m (492 ft)
198 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
