Danfoss iC7 Series

Design Guide | iC7 Series Liquid-cooled System Modules
Table 71: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 150 m (492 ft)
System module
and +AEU1, 2
kHz switching
frequency
(1)(1)
System module
and +AEU1, 3
kHz switching
frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss
[kW]
iC7-60SLIN07-170AE00F_ IR10L 170 2.07 0.08 2.58 0.10 0.01 0.07
iC7-60SLIN07-208AE00F_ IR10L 208 2.42 0.09 2.99 0.11 0.02 0.07
iC7-60SLIN07-261AE00F_ IR10L 261 2.98 0.11 3.58 0.13 0.02 0.07
iC7-60SLIN07-325AE00F_ IR10L 325 3.71 0.14 4.39 0.16 0.04 0.07
iC7-60SLIN07-365AE00F_ IR10L 365 4.66 0.18 5.40 0.20 0.04 0.07
iC7-60SLIN07-416AE00F_ IR10L 416 5.35 0.21 6.26 0.23 0.05 0.07
iC7-60SLIN07-465AE00F_ IR12L 465 5.25 0.18 6.48 0.23 0.03 0.13
iC7-60SLIN07-525AE00F_ IR12L 525 5.80 0.20 7.11 0.24 0.04 0.13
iC7-60SLIN07-590AE00F_ IR12L 590 6.53 0.22 7.84 0.26 0.06 0.13
iC7-60SLIN07-650AE00F_ IR12L 650 7.11 0.24 8.56 0.28 0.07 0.13
iC7-60SLIN07-730AE00F_ IR12L 730 8.73 0.29 10.29 0.35 0.08 0.13
iC7-60SLIN07-820AE00F_ IR12L 820 10.24 0.35 12.28 0.42 0.11 0.13
iC7-60SLIN07-945AE00F_ 2xIR12L 945 11.05 0.37 13.11 0.46 0.05 0.26
iC7-60SLIN07-1060E00F_ 2xIR12L 1060 11.64 0.40 14.34 0.49 0.08 0.26
iC7-60SLIN07-1230E00F_ 2xIR12L 1230 13.45 0.45 16.27 0.54 0.11 0.26
iC7-60SLIN07-1400E00F_ 2xIR12L 1400 15.37 0.51 18.39 0.60 0.13 0.26
iC7-60SLIN07-1500E00F_ 2xIR12L 1500 18.43 0.64 22.56 0.79 0.16 0.26
iC7-60SLIN07-1640E00F_ 2xIR12L 1640 20.21 0.69 24.56 0.84 0.19 0.26
iC7-60SLIN07-1795E00F_ 3xIR12L 1795 20.77 0.74 25.89 0.91 0.18 0.39
iC7-60SLIN07-2080E00F_ 3xIR12L 2080 24.32 0.83 29.42 1.00 0.20 0.39
iC7-60SLIN07-2300E00F_ 3xIR12L 2300 28.18 0.97 34.51 1.20 0.23 0.39
iC7-60SLIN07-2500E00F_ 3xIR12L 2500 30.86 1.05 37.45 1.28 0.31 0.39
iC7-60SLIN07-2830E00F_ 4xIR12L 2830 33.06 1.13 39.96 1.36 0.26 0.52
iC7-60SLIN07-3050E00F_ 4xIR12L 3050 37.52 1.29 45.79 1.59 0.31 0.52
iC7-60SLIN07-3260E00F_ 4xIR12L 3260 40.33 1.38 48.80 1.67 0.48 0.52
iC7-60SLIN07-3500E00F_ 5xIR12L 3500 40.96 1.40 49.46 1.68 0.33 0.66
iC7-60SLIN07-4035E00F_ 5xIR12L 4035 49.61 1.70 60.40 2.08 0.51 0.66
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 199
