Design Guide | iC7 Series Liquid-cooled System Modules
Table 47: Field Cable Sizes for INU Module, 525–690 V AC (continued)
Model code
Frame
(1)
I
N
[A] Motor cable
Cu [mm
2
]
Motor cable
Al [mm
2
]
Terminal
max. cable
size
Number of
grounding
terminals/
bolt size
Max.
number of
cables/ bolt
size
iC7-60SLIN07-5300E00F
x
5 410 28x(3x120+7
0)
28x(3x150+4
1)
300 Cu/Al 7/M8 28/M10
iC7-60SLIN07-5600E00F
x
7 x Ix12L
5 720 28x(3x120+7
0)
28x(3x185+5
7)
300 Cu/Al 7/M8 28/M10
iC7-60SLIN07-6100E00F
x
6 230 32x(3x120+7
0)
32x(3x185+5
7)
300 Cu/Al 8/M8 32/M10
iC7-60SLIN07-6400E00F
x
8 x Ix12L
6 540 32x(3x120+7
0)
32x(3x185+5
7)
300 Cu/Al 8/M8 32/M10
1) IM10L, IR10L, IM12L, or IR12L
10.4.5 Marine Cable Sizes for AFE or GC Modules 525–690 V AC
Table 48: Cable Sizes for AFE or GC Module 525–690 V AC for Marine Applications (Marine cables according to IEC 60092-352)
Model code
Frame
(1)
I
N
[A] Mains cable Cu
[mm
2
]
Terminal max.
cable size
Number of
grounding
terminals/
bolt size
Max. number
of cables/
bolt size
iC7-60SLxx07-236AE00Fx 245 2x(3x70) 150 Cu/Al 1/M8 3/M8
iC7-60SLxx07-300AE00Fx 310 2x(3x95) 150 Cu/Al 1/M8 3/M8
iC7-60SLxx07-334AE00Fx 345 3x(3x70) 150 Cu/Al 1/M8 3/M8
iC7-60SLxx07-380AE00Fx
Ax10L
390 3x(3x95) 150 Cu/Al 1/M8 3/M8
iC7-60SLxx07-425AE00Fx 435 3x(3x95) 150 Cu/Al 1/M8 6/M10
iC7-60SLxx07-475AE00Fx 490 3x(3x95) 150 Cu/Al 1/M8 6/M10
iC7-60SLxx07-530AE00Fx 545 4x(3x95) 150 Cu/Al 1/M8 6/M10
iC7-60SLxx07-595AE00Fx 610 4x(3x95) 150 Cu/Al 1/M8 6/M10
iC7-60SLxx07-670AE00Fx 690 5x(3x95) 150 Cu/Al 1/M8 6/M10
iC7-60SLxx07-760AE00Fx
Ax12L
770 5x(3x95) 150 Cu/Al 1/M8 6/M10
iC7-60SLxx07-850AE00Fx 870 6x(3x95) 150 Cu/Al 2/M8 12/M10
iC7-60SLxx07-945AE00Fx 970 6x(3x95) 150 Cu/Al 2/M8 12/M10
iC7-60SLxx07-1040E00Fx 1070 8x(3x95) 150 Cu/Al 2/M8 12/M10
iC7-60SLxx07-1230E00Fx 1260 8x(3x95) 150 Cu/Al 2/M8 12/M10
iC7-60SLxx07-1325E00Fx 1360 10x(3x95) 150 Cu/Al 2/M8 12/M10
iC7-60SLxx07-1500E00Fx
2 x Ax12L
1540 10x(3x95) 150 Cu/Al 2/M8 12/M10
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 171
