Table 47: Field Cable Sizes for INU Module, 525–690 V AC (continued)
Model code
Frame
(1)
I
N
[A] Motor cable
Cu [mm
2
]
Motor cable
Al [mm
2
]
Terminal
max. cable
size
Number of
grounding
terminals/
bolt size
Max.
number of
cables/ bolt
size
iC7-60SLIN07-945E00Fx 965 4x(3x150+70) 4x(3x240+72) 300 Cu/Al 2/M8 8/M10
iC7-60SLIN07-1060E00F
x
1 090 4x(3x185+95) 6x(3x150+41) 300 Cu/Al 2/M8 8/M10
iC7-60SLIN07-1230E00F
x
1 260 4x(3x240+12
0)
6x(3x185+57) 300 Cu/Al 2/M8 8/M10
iC7-60SLIN07-1400E00F
x
1 430 4x(3x240+12
0)
8x(3x150+41) 300 Cu/Al 2/M8 8/M10
iC7-60SLIN07-1500E00F
x
1 540 8x(3x120+70) 8x(3x150+41) 300 Cu/Al 2/M8 8/M10
iC7-60SLIN07-1640E00F
x
2 x Ix12L
1 680 8x(3x120+70) 8x(3x185+57) 300 Cu/Al 2/M8 8/M10
iC7-60SLIN07-1795E00F
x
1 840 9x(3x120+70) 9x(3x185+57) 300 Cu/Al 3/M8 12/M10
iC7-60SLIN07-2080E00F
x
2 130 9x(3x150+70) 12x(3x150+4
1)
300 Cu/Al 3/M8 12/M10
iC7-60SLIN07-2300E00F
x
2 350 12x(3x120+7
0)
12x(3x150+4
1)
300 Cu/Al 3/M8 12/M10
iC7-60SLIN07-2460E00F
x
3 x Ix12L
2 560 12x(3x120+7
0)
12x(3x185+5
7)
300 Cu/Al 3/M8 12/M10
iC7-60SLIN07-2830E00F
x
2 890 12x(3x150+7
0)
16x(3x150+4
1)
300 Cu/Al 4/M8 16/M10
iC7-60SLIN07-3050E00F
x
3 120 16x(3x120+7
0)
16x(3x185+5
7)
300 Cu/Al 4/M8 16/M10
iC7-60SLIN07-3260E00F
x
4 x Ix12L
3 330 16x(3x120+7
0)
16x(3x185+5
7)
300 Cu/Al 4/M8 16/M10
iC7-60SLIN07-3500E00F
x
3 580 15x(3x150+7
0)
20x(3x150+4
1)
300 Cu/Al 5/M8 20/M10
iC7-60SLIN07-4035E00F
x
5 x Ix12L
4 120 20x(3x120+7
0)
20x(3x185+5
7)
300 Cu/Al 5/M8 20/M10
iC7-60SLIN07-4400E00F
x
4 500 18x(3x150+7
0)
24x(3x150+4
1)
300 Cu/Al 6/M8 24/M10
iC7-60SLIN07-4850E00F
x
6 x Ix12L
4 960 24x(3x120+7
0)
24x(3x185+5
7)
300 Cu/Al 6/M8 24/M10
