Danfoss iC7 Series Design Guide

Table 75: Power Loss for INU Modules with Option +AEU1, Motor Cable Maximum Length 150 m (492 ft) (continued)
System module
and +AEU1,
2kHz switching
frequency
(1)(1)
System module
and +AEU1,
3kHz switching
frequency
(1)
+AKFX
(2)(2)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss [kW]
iC7-60SLINB5-590AE00F_ IR12L 590 4.59 0.15 5.45 0.17 0.06 0.072
iC7-60SLINB5-650AE00F_ IR12L 650 5.16 0.17 6.17 0.19 0.07 0.072
iC7-60SLINB5-730AE00F_ IR12L 730 6.08 0.20 7.17 0.22 0.08 0.072
iC7-60SLINB5-820AE00F_ IR12L 820 7.18 0.24 8.49 0.27 0.11 0.072
iC7-60SLINB5-1060AE00F_ 2xIR12L 1060 8.16 0.26 9.73 0.30 0.08 0.144
iC7-60SLINB5-1230AE00F_ 2xIR12L 1230 9.66 0.31 11.42 0.35 0.11 0.144
iC7-60SLINB5-1400AE00F_ 2xIR12L 1400 11.27 0.36 13.27 0.40 0.13 0.144
iC7-60SLINB5-1500AE00F_ 2xIR12L 1500 12.84 0.42 15.23 0.48 0.16 0.144
iC7-60SLINB5-1640AE00F_ 2xIR12L 1640 14.36 0.47 16.98 0.53 0.19 0.144
iC7-60SLINB5-1795AE00F_ 3xIR12L 1795 14.43 0.47 17.18 0.54 0.18 0.216
iC7-60SLINB5-2080AE00F_ 3xIR12L 2080 17.14 0.56 20.25 0.63 0.20 0.216
iC7-60SLINB5-2300AE00F_ 3xIR12L 2300 19.77 0.65 23.45 0.74 0.23 0.216
iC7-60SLINB5-2500AE00F_ 3xIR12L 2500 21.97 0.73 25.98 0.82 0.31 0.216
iC7-60SLINB5-2830AE00F_ 4xIR12L 2830 23.42 0.76 27.64 0.86 0.26 0.288
iC7-60SLINB5-3050AE00F_ 4xIR12L 3050 26.15 0.86 31.07 0.98 0.31 0.288
iC7-60SLINB5-3260AE00F_ 4xIR12L 3260 28.57 0.94 33.69 1.06 0.48 0.288
1) System module and the dU/dt Filter in the integration unit
2) DC fuses
10.7.11 Power Losses of INU Modules with +AEU1, Voltage Class B5, Motor Cable Maximum Length
50 m (164 ft)
l The specifications for the values in the table
¢ Inverter module
¢ 380–500 V AC (465–800 V DC)
¢ DC voltage 594 V DC
¢ Option +AEU1
¢ Switching frequency 2 kHz or 3 kHz
¢ Modulator type 2
¢ Motor cable length a maximum of 50 m (164 ft)
208 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
