Design Guide | iC7 Series Liquid-cooled System Modules
l 10.7.7 Power Losses of INU Modules with +AEU1, Voltage Class 07, Motor Cable Maximum Length 50 m (164 ft)
l 10.7.8 Power Losses of INU Modules without Options, Voltage Class 07, Modulator Type 1 – SVPWM
l 10.7.9 Power Losses of INU Modules without Options, Voltage Class 07, Modulator Type 2 – Optimized
l 10.7.10 Power Losses of INU Modules with +AEU1, Voltage Class B5, Motor Cable Maximum Length 150 m (492 ft)
l 10.7.11 Power Losses of INU Modules with +AEU1, Voltage Class B5, Motor Cable Maximum Length 50 m (164 ft)
l 10.7.12 Power Losses of INU Modules without Options, Voltage Class B5, Modulator Type 1 – SVPWM
l 10.7.13 Power Losses of INU Modules without Options, Voltage Class B5, Modulator Type 2 – Optimized
l 10.7.14 Power Losses of DC/DC Converter Modules, Voltage Class 07
l 10.7.15 Power Losses of DC/DC Converter Modules, Voltage Class B5
10.7.2 Power Losses of AFE and GC Modules, Voltage Class 07
l The specifications for the values in the table
¢ AFE or GC module
¢ 525–690 V AC (640–1100 V DC)
¢ DC voltage 1025 V DC
¢ Modulator type 4
n The default modulator type for grid converters is type 5, which results in slightly lower losses than given in the table.
Table 67: Power Loss for AFE and GC Modules
System module
+AKFX
(1)(1)
Model code Frame Rated
current
I
L(1/5)
[A]
Power loss
to liquid
[kW]
Power loss
to air [kW]
Power loss
to air [kW]
Standby
loss [kW]
iC7-60SL3A07-236AE00F_ AM10L 236 3.29 0.03 0.01 0.07
iC7-60SL3A07-300AE00F_ AM10L 300 4.44 0.04 0.02 0.07
iC7-60SL3A07-334AE00F_ AM10L 334 5.13 0.05 0.02 0.07
iC7-60SL3A07-380AE00F_ AM10L 380 6.16 0.06 0.03 0.07
iC7-60SL3A07-425AE00F_ AM12L 425 5.82 0.06 0.01 0.13
iC7-60SL3A07-475AE00F_ AM12L 475 6.63 0.07 0.02 0.13
iC7-60SL3A07-530AE00F_ AM12L 530 7.58 0.08 0.03 0.13
iC7-60SL3A07-595AE00F_ AM12L 595 8.79 0.09 0.04 0.13
iC7-60SL3A07-670AE00F_ AM12L 670 10.31 0.10 0.05 0.13
iC7-60SL3A07-760AE00F_ AM12L 760 12.32 0.12 0.07 0.13
iC7-60SL3A07-850AE00F_ 2xAM12L 850 11.64 0.12 0.02 0.26
iC7-60SL3A07-945AE00F_ 2xAM12L 945 13.19 0.13 0.04 0.26
iC7-60SL3A07-1040E00F_ 2xAM12L 1040 14.81 0.15 0.04 0.26
iC7-60SL3A07-1230E00F_ 2xAM12L 1230 18.36 0.19 0.07 0.26
iC7-60SL3A07-1325E00F_ 2xAM12L 1325 20.30 0.21 0.10 0.26
iC7-60SL3A07-1500E00F_ 2xAM12L 1500 24.17 0.24 0.13 0.26
iC7-60SL3A07-1700E00F_ 3xAM12L 1700 24.76 0.25 0.11 0.39
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 193
