Danfoss iC7 Series Design Guide

Table 55: DC-bus Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type (continued)
Model code
(1)(1)
Frame Rated
current
(I
L
) [A]
Number
of fuses
Fuse
size
Part number
(Mersen)
Fuse U
n
[V]
Fuse I
n
[A]
I
cp, mr
[A]
iC7-60SLDCxx-720AE00F4 720 4 73 PC73UD13C630TF 1250 630 5900
iC7-60SLDCxx-840AE00F4 840 4
iC7-60SLDCxx-960AE00F4 960 4
73 PC73UD13C800TF 1250 800 8900
iC7-60SLDCxx-1080E00F4 1080 4
iC7-60SLDCxx-1200E00F4
DR12L
1200 4
73 PC73UD12C900TF 1200 900 10200
iC7-60SLDCxx-1440E00F4 1440 8 73 PC73UD13C630TF 1250 630 5900
iC7-60SLDCxx-1680E00F4 1680 8
iC7-60SLDCxx-1920E00F4 1920 8
73 PC73UD13C800TF 1250 800 8900
iC7-60SLDCxx-2160E00F4 2160 8
iC7-60SLDCxx-2400E00F4
2 x DR12L
2400 8
73 PC73UD12C900TF 1200 900 10200
iC7-60SLDCxx-2880E00F4 2880 12 73 PC73UD13C800TF 1250 800 8900
iC7-60SLDCxx-3240E00F4 3240 12
iC7-60SLDCxx-3600E00F4
3 x DR12L
3600 12
73 PC73UD12C900TF 1200 900 10200
1) xx = B5 or 07
10.5.6 Source DC+ Fuses for DC/DC Converter, IP00/Open Type
Table 56: Source DC+ Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type
Model code
(1)(1)
Frame Rated
current
(I
L
) [A]
Number
of fuses
Fuse
size
Part number
(Mersen)
Fuse U
n
[V]
Fuse I
n
[A]
I
cp, mr
[A]
iC7-60SLDCxx-300AE00F4 300 3
iC7-60SLDCxx-360AE00F4 360 3
iC7-60SLDCxx-420AE00F4 420 3
72 D72SG120V250QF 1200 250 1600
iC7-60SLDCxx-480AE00F4 480 3
iC7-60SLDCxx-570AE00F4
DR10L
570 3
72 D72SG120V315QF 1200 315 2200
iC7-60SLDCxx-720AE00F4 720 3
iC7-60SLDCxx-840AE00F4 840 3
iC7-60SLDCxx-960AE00F4 960 3
272 D272SG120V500QF 1200 500 3100
iC7-60SLDCxx-1080E00F4 1080 3
iC7-60SLDCxx-1200E00F4
DR12L
1200 3
272 D272SG120V630QF 1200 630 4400
180 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
