Danfoss iC7 Series Design Guide

Table 68: Power Loss for AFE and GC Modules with Options +AEZ1 and +AEZ3 (continued)
System module and
+AEZ1
(1)(1)
System module and
+AEZ3
(2)(2)
+AKFX
(3)(3)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss,
system
module
and
+AEZ1
[kW]
iC7-60SL3A07-5040E00F_ 7xAR12L 5040 91.0 3.96 - - 0.46 0.96
iC7-60SL3A07-5400E00F_ 8xAR12L 5400 95.0 4.13 98.5 6.44 0.38 1.10
iC7-60SL3A07-5750E00F_ 8xAR12L 5750 103.8 4.51 107.8 7.16 0.53 1.10
1) System module and the LC Filter in the integration unit
2) System module and the LC Filter in the integration unit and the L Filter
3) DC fuses
10.7.4 Power Losses of AFE and GC Modules, Voltage Class B5
l The specifications for the values in the table
¢ AFE or GC module
¢ 380–500 V AC (465–800 V DC)
¢ DC voltage 594 V DC
¢ Modulator type 4
n The default modulator type for grid converters is type 5, which results in slightly lower losses than given in the table.
Table 69: Power Loss for AFE and GC Modules
System module
+AKFX
(1)(1)
Model code Frame Rated
current
I
L(1/5)
[A]
Power loss
to liquid
[kW]
Power loss
to air [kW]
Power loss
to air [kW]
Standby
loss [kW]
iC7-60SL3AB5-261A AM10L 261 2.50 0.03 0.02 0.04
iC7-60SL3AB5-325A AM10L 325 3.28 0.03 0.02 0.04
iC7-60SL3AB5-380A AM10L 380 4.02 0.04 0.03 0.04
iC7-60SL3AB5-425A AM12L 425 3.96 0.04 0.01 0.07
iC7-60SL3AB5-475A AM12L 475 4.49 0.05 0.02 0.07
iC7-60SL3AB5-530A AM12L 530 5.10 0.05 0.03 0.07
iC7-60SL3AB5-595A AM12L 595 5.87 0.06 0.04 0.07
iC7-60SL3AB5-670A AM12L 670 6.81 0.07 0.05 0.07
iC7-60SL3AB5-760A AM12L 760 8.04 0.08 0.07 0.07
iC7-60SL3AB5-850A 2xAM12L 850 7.92 0.08 0.02 0.14
iC7-60SL3AB5-945A 2xAM12L 945 8.93 0.09 0.04 0.14
196 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
