Danfoss iC7 Series Design Guide

Design Guide | iC7 Series Liquid-cooled System Modules
Table 68: Power Loss for AFE and GC Modules with Options +AEZ1 and +AEZ3
System module and
+AEZ1
(1)(1)
System module and
+AEZ3
(2)(2)
+AKFX
(3)(3)
Model code Frame Rated
current
I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
liquid
[kW]
Power
loss to
air [kW]
Power
loss to
air [kW]
Standby
loss,
system
module
and
+AEZ1
[kW]
iC7-60SL3A07-236AE00F_ AR10L 236 4.1 0.19 4.2 0.27 0.01 0.07
iC7-60SL3A07-300AE00F_ AR10L 300 5.6 0.27 5.8 0.40 0.02 0.07
iC7-60SL3A07-334AE00F_ AR10L 334 6.5 0.31 6.7 0.47 0.02 0.07
iC7-60SL3A07-380AE00F_ AR10L 380 7.8 0.38 8.1 0.59 0.03 0.07
iC7-60SL3A07-425AE00F_ AR12L 425 6.6 0.25 6.7 0.32 0.01 0.14
iC7-60SL3A07-475AE00F_ AR12L 475 7.5 0.29 7.7 0.38 0.02 0.14
iC7-60SL3A07-530AE00F_ AR12L 530 8.6 0.35 8.8 0.46 0.03 0.14
iC7-60SL3A07-595AE00F_ AR12L 595 10.0 0.40 10.2 0.54 0.04 0.14
iC7-60SL3A07-670AE00F_ AR12L 670 11.7 0.52 12.0 0.69 0.05 0.14
iC7-60SL3A07-760AE00F_ AR12L 760 14.0 0.61 14.3 0.84 0.07 0.14
iC7-60SL3A07-850AE00F_ 2xAR12L 850 13.3 0.48 13.6 0.71 0.02 0.27
iC7-60SL3A07-945AE00F_ 2xAR12L 945 15.1 0.57 15.5 0.85 0.04 0.27
iC7-60SL3A07-1040E00F_ 2xAR12L 1040 16.9 0.69 17.4 1.03 0.04 0.27
iC7-60SL3A07-1230E00F_ 2xAR12L 1230 20.9 0.89 21.6 1.35 0.07 0.27
iC7-60SL3A07-1325E00F_ 2xAR12L 1325 23.2 1.00 24.0 1.55 0.10 0.27
iC7-60SL3A07-1500E00F_ 2xAR12L 1500 27.6 1.23 28.7 1.95 0.13 0.27
iC7-60SL3A07-1700E00F_ 3xAR12L 1700 28.2 1.14 - - 0.11 0.41
iC7-60SL3A07-1800E00F_ 3xAR12L 1800 30.4 1.25 - - 0.09 0.41
iC7-60SL3A07-2000E00F_ 3xAR12L 2000 35.0 1.51 - - 0.14 0.41
iC7-60SL3A07-2250E00F_ 3xAR12L 2250 41.4 1.83 - - 0.20 0.41
iC7-60SL3A07-2500E00F_ 4xAR12L 2500 42.8 1.79 44.2 2.76 0.17 0.55
iC7-60SL3A07-2650E00F_ 4xAR12L 2650 46.3 1.96 48.0 3.07 0.19 0.55
iC7-60SL3A07-2940E00F_ 4xAR12L 2940 53.6 2.33 55.7 3.71 0.28 0.55
iC7-60SL3A07-3120E00F_ 5xAR12L 3120 53.4 2.25 - - 0.18 0.69
iC7-60SL3A07-3600E00F_ 5xAR12L 3600 65.0 2.82 - - 0.33 0.69
iC7-60SL3A07-3900E00F_ 6xAR12L 3900 67.7 2.85 70.0 4.44 0.25 0.82
iC7-60SL3A07-4320E00F_ 6xAR12L 4320 78.0 3.24 81.0 5.24 0.40 0.82
iC7-60SL3A07-4750E00F_ 7xAR12L 4750 83.7 3.63 - - 0.34 0.96
Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A | 195
