Danfoss iC7 Series Design Guide

Table 45: Field Cable Sizes for AFE and GC Modules, 525–690 V AC
Model code
Frame
(1)(1)
I
N
[A]
Cu [mm
2
] Al [mm
2
]
iC7-60SLxx07-236AE00Fx 245 3x150+70 3x240+72
iC7-60SLxx07-300AE00Fx 310 3x240+120 2x(3x120+41)
iC7-60SLxx07-334AE00Fx 345 2x(3x95+50) 2x(3x150+41)
iC7-60SLxx07-380AE00Fx
Ax10L
390 2x(3x120+70) 2x(3x185+57)
iC7-60SLxx07-425AE00Fx 435 2x(3x120+70) 2x(3x185+57)
iC7-60SLxx07-475AE00Fx 490 2x(3x150+70) 2x(3x240+72)
iC7-60SLxx07-530AE00Fx 545 2x(3x185+70) 3x(3x150+41)
iC7-60SLxx07-595AE00Fx 610 2x(3x240+120) 3x(3x185+57)
iC7-60SLxx07-670AE00Fx 690 4x(3x120+70) 4x(3x150+41)
iC7-60SLxx07-760AE00Fx
Ax12L
770 4x(3x120+70) 4x(3x150+41)
iC7-60SLxx07-850AE00Fx 870 4x(3x120+70) 4x(3x185+57)
iC7-60SLxx07-945AE00Fx 970 4x(3x150+70) 4x(3x240+72)
iC7-60SLxx07-1040E00Fx 1070 4x(3x185+95) 6x(3x150+41)
iC7-60SLxx07-1230E00Fx 1260 4x(3x240+120) 6x(3x185+57)
iC7-60SLxx07-1325E00Fx 1360 8x(3x120+70) 8x(3x150+41)
iC7-60SLxx07-1500E00Fx
2 x Ax12L
1540 8x(3x120+70) 8x(3x150+41)
iC7-60SLxx07-1700E00Fx 1740 6x(3x185+95) 9x(3x150+41)
iC7-60SLxx07-1800E00Fx 1840 6x(3x240+120) 9x(3x185+57)
iC7-60SLxx07-2000E00Fx 2050 6x(3x240+120) 9x(3x240+72)
iC7-60SLxx07-2250E00Fx
3 x Ax12L
2300 12x(3x120+70) 9x(3x240+72)
iC7-60SLxx07-2500E00Fx 2560 8x(3x240+120) 12x(3x185+57)
iC7-60SLxx07-2650E00Fx 2710 12x(3x150+70) 12x(3x240+72)
iC7-60SLxx07-2940E00Fx
4 x Ax12L
3002 12x(3x150+70) 12x(3x240+72)
iC7-60SLxx07-3120E00Fx 3190 10x(3x240+120) 15x(3x185+57)
iC7-60SLxx07-3600E00Fx
5 x Ax12L
3680 15x(3x150+70) 15x(3x240+72)
iC7-60SLxx07-3900E00Fx 3990 18x(3x150+70) 18x(3x240+72)
iC7-60SLxx07-4320E00Fx
6 x Ax12L
4410 18x(3x150+70) 18x(3x240+72)
iC7-60SLxx07-4750E00Fx 4850 21x(3x150+70) 21x(3x240+72)
iC7-60SLxx07-5040E00Fx
7 x Ax12L
5150 21x(3x150+70) 21x(3x240+72)
iC7-60SLxx07-5400E00Fx 5520 24x(3x150+70) 24x(3x240+72)
iC7-60SLxx07-5750E00Fx
8 x Ax12L
5870 24x(3x150+70) 24x(3x240+72)
1) AM10L, AR10L, AM12L, or AR12L
168 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
