Danfoss iC7 Series Design Guide

Table 78: Power Loss for INU Modules without Options, Modulator Type 2
System module,
2 kHz switching
frequency
System module,
3 kHz switching
frequency
System module,
4 kHz switching
frequency
System module,
6 kHz switching
frequency
+AKFX
(1)
(1)
Model code Frame Rated
curren
t I
L(1/5)
[A]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss to
liquid
[kW]
Power
loss
to air
[kW]
Power
loss
to air
[kW]
iC7-60SLINB5-206AE0
0F_
IM10L 206 1.05 0.01 1.25 0.01 1.33 0.01 1.60 0.02 0.02
iC7-60SLINB5-245AE0
0F_
IM10L 245 1.29 0.01 1.53 0.02 1.62 0.02 1.94 0.02 0.02
iC7-60SLINB5-302AE0
0F_
IM10L 302 1.67 0.02 1.98 0.02 2.08 0.02 2.49 0.02 0.04
iC7-60SLINB5-385AE0
0F_
IM10L 385 2.30 0.02 2.72 0.03 2.86 0.03 3.42 0.03 0.04
iC7-60SLINB5-416AE0
0F_
IM10L 416 2.57 0.03 3.04 0.03 3.19 0.03 3.81 0.04 0.05
iC7-60SLINB5-525AE0
0F_
IM10L 525 2.81 0.03 3.32 0.03 3.51 0.04 4.19 0.04 0.04
iC7-60SLINB5-590AE0
0F_
IM12L 590 3.24 0.03 3.84 0.04 4.04 0.04 4.84 0.05 0.06
iC7-60SLINB5-650AE0
0F_
IM12L 650 3.67 0.04 4.41 0.04 4.59 0.05 5.47 0.05 0.07
iC7-60SLINB5-730AE0
0F_
IM12L 730 4.29 0.04 5.07 0.05 5.33 0.05 6.37 0.06 0.08
iC7-60SLINB5-820AE0
0F_
IM12L 820 5.04 0.05 5.95 0.06 6.26 0.06 7.44 0.07 0.11
iC7-60SLINB5-1060AE
00F_
2xIM1
2L
1060 5.67 0.06 6.72 0.07 7.11 0.07 8.51 0.09 0.08
iC7-60SLINB5-1230AE
00F_
2xIM1
2L
1230 6.86 0.07 8.09 0.08 8.54 0.09 10.22 0.10 0.11
iC7-60SLINB5-1400AE
00F_
2xIM1
2L
1400 8.10 0.08 9.58 0.10 10.10 0.10 12.06 0.12 0.13
iC7-60SLINB5-1500AE
00F_
2xIM1
2L
1500 8.91 0.09 10.51 0.11 11.07 0.11 13.23 0.13 0.16
iC7-60SLINB5-1640AE
00F_
2xIM1
2L
1640 10.07 0.10 11.90 0.12 12.51 0.13 14.87 0.15 0.19
iC7-60SLINB5-1795AE
00F_
3xIM1
2L
1795 9.90 0.10 11.72 0.12 12.36 0.12 14.76 0.15 0.18
212 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
