Danfoss iC7 Series Design Guide

2
1
2
1
1
e30bg381.11
Figure 16: Mounting Holes of the System Module, AFE with the Integration Unit
1 Mounting holes in aluminum parts 2 Mounting holes in sheet metal parts
3. Attach the system module to the mounting brackets of the cabinet.
The mounting brackets are not included in the delivery.
32 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
