Datalogic DS8100 User Manual

User Interface
90 DX8210 Barcode Scanner
Example 4
Code label setting#1 = Code 93
Code label setting#2 = Interleaved 2/5
Code label setting#3= EAN-8
Code label setting#4= UPC-A
Logical Combination Rule = 1^2&3^4
Defines 2 groups, each of them expecting one of the defined code types. The first
group may expect a Code 93 label or an Interleaved 2/5 label. The second group
may expect an EAN-8 label or an UPC-A label.
Decoded Code Symbology
Output Message
First
Label
#1
Second
Label
#1
Third-
Label
#1
Label
#2
--- --- --- --- <Header><Global No Read Message><Terminator>
X --- --- --- <Header><Global No Read Message><Terminator>
--- X --- --- <Header><Global No Read Message><Terminator>
--- --- X --- <Header><Global No Read Message><Terminator>
--- --- --- X <Header><Global No Read Message><Terminator>
XXX---
<Header><EAN 8 data><DPS><EAN 8
data><DPS><EAN 8 data><Terminator>
X X --- X
<Header><EAN 8 data><DPS><EAN 8
data><DPS><U{PD-A data><Terminator>
XXXX
<Header><EAN 8 data><DPS><EAN 8 data><DPS>
<First decoded code/Multiple Read Message
string><Terminator>
Decoded Code Symbology
Output Message
Label
#1
Label
#2
Label
#3
Label
#4
--- --- --- --- <Header><Global No Read Message><Terminator>
X --- --- --- <Header><Global No Read Message><Terminator>
--- X --- --- <Header><Global No Read Message><Terminator>
--- --- X --- <Header><Global No Read Message><Terminator>
--- --- --- X <Header><Global No Read Message><Terminator>
X X --- --- <Header><Global No Read Message><Terminator>
X --- X X
<Header><Code93><DPS>< First decoded code/Multi-
ple Read Message string><Terminator>
XXX---
<Header><First decoded code/Multiple Read Message
string><DPS><EAN 8 data><Terminator>
--- X X X
<Header>< Interleaved 2/5 data><DPS>< First
decoded code/Multiple Read Message string ><Termi-
nator>
X --- X ---
<Header><Code 93 data><DPS><EAN 8 data><Termi-
nator>
