User Interface
120
DX8210 Barcode Scanner
Monitor Settings
Conveyor Speed Check Type
Select Percentage or Absolute from the drop-down list to determine how the
conveyor speed is evaluated.
Max Conveyor Speed Percent Error (%)
In the text field provided, enter the percentage of discrepancy allowed in the
conveyor speed before an error is sent. This option is available when Percentage is
selected from the Conveyor Speed Check Type drop-down list.
Max Conveyor Speed Absolute Error (mm/s)
In the text field provided, enter the milliseconds of discrepancy allowed in the
conveyor speed before an error is sent. This option is available when Absolute is
selected from the Conveyor Speed Check Type drop-down list.
Input Timeout (secs)
Enter a time interval in seconds, after which the input will be checked for errors. If
an error is found, it will be sent to WebSentinel.
Message Settings
Parcel Message Type
Select Standard, Extended, or Extended ADP from the drop-down to specify the
type of message.
Extended – WebSentinel PLUS versions earlier than 1.6.0.1369
Extended ADP – WebSentinel PLUS versions 1.6.0.1369 and later
WebSentinel – Partial Read Is Treated As
Select No Read or Good Read from the drop-down to specify how a partial read is
treated.
3. When you have finished making changes, click Update All to save all pend-
ing changes, click Reset Al
l to revert to all previously saved values, and click
Reset Page to revert to previous saved values on the current page.
