Scanning Features ENTER/EXIT PROGRAMMING MODE

106

Gryphon™ I GD4100/GM4100/GBT4100/L GD4300

Green Spot Duration

Specifies the duration of the good read pointer beam after a good read.

Green Spot Duration = Disable (Green Spot is Off )

Green Spot Duration = Short (300 msec)

DEFAULT

Green Spot Duration = Medium (500 msec)

Green Spot Duration = Long (800 msec)

Default Chapter3
