Interface Selection
Product Reference Guide
29
Interface Selection
Upon completing the physical connection between the reader and its host, proceed to Table 1
starting on page 30 to select the interface type the reader is connected to (for example: RS-232,
Keyboard Wedge, USB, etc.). Scan the appropriate barcode in that section to configure your
system’s correct interface type.
Each reader model
will support one of the following sets of host interfaces:
General Purpose Models Retail Point of Sale Models
•RS-232
• RS-232 OPOS
•USB
• Keyboard Wedge
• Wand Emulation
•RS-232
• RS-232 OPOS
•USB
• IBM 46XX
Setting the Interface
Scan the programming barcode from this section which selects the appropriate interface type
matching the system the reader will be connected to. Next, proceed to the corresponding
section in this manual (also listed in Table 1 starting on page 30) to configure any desired
settings and features associated with that interface.
Unlike some programming features and options, interface selections require that
you scan only one programming barcode label. DO NOT scan an ENTER/EXIT bar-
code prior to scanning an interface selection barcode.
Some interfaces require the scanner to star
t in the disabled stat
e when powered
up. If additional scanner configuration is desired while in this state, pull the trig-
ger and hold it for five seconds. The scanner will change to a state that allows pro-
gramming with barcodes.
