Setup
20 Gryphon™ I GD4100/GM4100/GBT 4100/L GD4300
Figure 7. Other Interface Connections
U
S
B
I
B
M
K
e
y
b
o
a
r
d
W
e
d
g
e
or...
or...
Specific cables are required for connection to different hosts. The connec-
tors illustrated above are examples only. Ac
tual connectors may vary from
those illustrated, but the steps to connect the reader remain the same.
RF Models
The power supply connects directly to the base (not on the cable's jack) for all configurations.
For all interfaces (except RS-232) a power supply is recommended but not necessary, because
the base can be powered from the Host. When the base is powered from the Host, select a slow
charge rate.
Configuring the Base Station
The base charger/station may be configured in desk application to hold the reader in two
different positions, either a horizontal or standing position, in order to provide the most
comfortable use depending on needs.
Standing
Horizontal
