Product Reference Guide 9
Chapter 1
Introduction
About this Manual
This Product Reference Guide (PRG) is provided for users seeking advanced technical
information, including connection, programming, maintenance and specifications. The Quick
Reference Guide (QRG) and other publications associated with this product are downloadable
free of charge from the website listed on the back cover of this manual.
Overview
Chapter 1, (this chapter) presents information about manual conventions, and an overview of
the reader, its features and operation.
Chapter 2, Setup presents information about unpacking, cable connection
information and
setting up the reader.
Chapter 3, Configuration Using Barcodes provides instructions and barcode labels for
customizing your reader. There are different sections for
interface types, general features, data
formatting, symbology-specific and model-specific features.
Chapter 4, Wireless Features describes options and programming related to radio
communication features for the RF variants of the Gryphon family.
Chapter 5, Laser Features describes options and programming specific to laser models.
Chapter 6, References provides background information and
detailed instructions for
more
complex programming items.
Chapter 7, Message Formatting provides
details for programming options.
A
ppendix A, Technical Specifications lists physical and performance cha
racteristics, as well as
environmental and regulatory specifications. It also provides standard cable pin-outs and LED/
Beeper functions.
A
ppendix B, Standard Defaults references common factory default
settings for reader features
and options.
Appendix C, Sample Bar Codes offers sample barcodes of several common symbologies.
Appendix D, Keypad includes numeric barcodes to be scan
ned for certain
parameter settings.
Appendix E, Scancode Tables lists control character emulation information for Wedge and USB
Keyboard interfaces.
