Code 11 ENTER/EXIT PROGRAMMING MODE

216

Gryphon™ I GD4100/GM4100/GBT4100/L GD4300

Code 11 Set Length 2

This feature specifies one of the barcode lengths for Code 11 Length Control. Length 2 is the

maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length

Mode. Length includes the barcode’s check and data characters.

The length can be set from 2 to 50 characters. A setting of 0 specifies to i

gnore this length (only

one fixed length).

Table 19 provides examples for setting Length 2. See page 303 for detailed instructions on

setting this feature.

Table 19. Code 11 Length 2 Setting Examples

STEP ACTION EXAMPLES

Desired Setting (pad with

leading zer

oes)

00 (Ignore This

Length)

07 Characters 15 Characters 50 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT CODE 11 LENGTH 2 SETTING

Scan Two Characters From

Appendix D, Keypad

‘0’ and ‘0’ ‘0’ and ‘7’ ‘0’ and ‘F’ ‘3’ AND 2’

5 Scan ENTER/EXIT PROGRAMMING MODE

Select Code 11 Length 2 Setting

Make a mistake? Scan the CANCEL barcode to abort and not

save the en

try string. You can then start again at the begin-

ning.

CANCEL

DEFAULT

50 = Length 2 is 50 Characters
