ENTER/EXIT PROGRAMMING MODE Code 128 Length Control

Product Reference Guide 157

Code 128 Length Control

This feature specifies either variable length decoding or fixed length decoding for the Code 128

symbology. See page 302 for more information..

DEFAULT

Code 128 Length Control = Variable Length

Code 128 Length Control = Fixed Length

Default Chapter3
