GS1 DataBar™ Limited ENTER/EXIT PROGRAMMING MODE

228

Gryphon™ I GD4100/GM4100/GBT4100/L GD4300

GS1 DataBar™ Limited Minimum Reads

This feature specifies the minimum number of consecutive times a GS1 DataBar™ Limited

label must be decoded before it is accepted as good read

DEFAULT

GS1 DataBar™ Limited Minimum Reads = 1

GS1 DataBar™ Limited Minimum Reads = 2

GS1 DataBar™ Limited Minimum Reads = 3

GS1 DataBar™ Limited Minimum Reads = 4

Default Chapter3
