Appendix A. Modbus Protocol
MS300
A-12
Function Name
Modbus
Address
Attribute
(Function
Code)
Size Description
Counter value
2109H R(03H)
U16
The present value of MI
Output power factor
angle
210AH R(03H)
Drive’s output power factor angle (XXX.X°) (0.0–180.0°)
Output torque
210BH R(03H) Output torque (XXX.X %)
Motor actual speed
210CH R(03H) Actual motor speed (XXXXX rpm)
Number of PG
feedback pulses
210DH R(03H) Number of PG feedback pulses (0~65535)
Number of pulse
commands
210EH R(03H) Number of PG2 pulse commands (0~65535)
Power output
210FH R(03H) Drive’s output power (X.XXX kW)
Multi-function display
2116H R(03H)
Display the low word value (Pr.00-04) of user-defined
items,
the value is low 16 bits data.
Maximum user-
defined value
211BH R(03H)
Maximum Operation Frequency (Pr.01-00) or Maximum
User-defined Value (Pr.00-26)
 When Pr.00-26 is 0, this value is equal to Pr.01-00
setting
 When Pr.00-26 is not 0, and the command source is
keypad, this value = Pr.00-24 × Pr.00-26 / Pr.01-00
 When Pr.00-26 is not 0, and the command source is
485, this value = Pr.09-10 × Pr.00-26 / Pr.01-00
Output current digit
211FH R(03H) High byte: Current digit (display)
Multi-point positioning
2157H R(03H) Display the position of multi-point positioning
