Chapter 7 Optional AccessoriesMH300
7-10
7-3 Fuse Specification Chart
 Fuse specifications lower than the table shown below are allowed.
 For installation in the United States, branch circuit protection must be provided in accordance with
the National Electrical Code (NEC) and any applicable local codes. Use UL classified fuses to fulfill
this requirement.
 For installation in Canada, branch circuit protection must be provided in accordance with Canadian
Electrical Code and any applicable provincial codes. Use UL classified fuses to fulfill this requirement.
115V, single-phase
Model
Input Current (A) Specification of Fuse (600 V
AC
)
Normal Duty Heavy Duty I (A) P/N
VFD1A6MH11ANSXX
VFD1A6MH11ENSXX
6.8 6.0 7.2 Class T JJS-10
VFD2A5MH11ANSXX
VFD2A5MH11ENSXX
10.1 9.4 10.8 Class T JJS-10
VFD5A0MH11ANSXX
VFD5A0MH11ENSXX
20.6 18.8 22 Class T JJS-25
Table 7-12
230V, single-phase
Model
Input Current (A) Specification of Fuse (600 V
AC
)
Normal Duty Heavy Duty I (A) Normal Duty
VFD1A6MH21ANSXX
VFD1A6MH21ENSXX
VFD1A6MH21AFSXX
3.8 3.4 7.2 Class T JJS-10
VFD2A8MH21ANSXX
VFD2A8MH21ENSXX
VFD2A8MH21AFSXX
6.7 5.9 12.8 Class T JJS-15
VFD5A0MH21ANSXX
VFD5A0MH21ENSXX
VFD5A0MH21AFSXX
10.9 10.5 20.8 Class T JJS-20
VFD7A5MH21ANSXX
VFD7A5MH21ENSXX
VFD7A5MH21AFSXX
17.9 15.8 34 Class T JJS-35
VFD11AMH21ANSXX
VFD11AMH21ENSXX
VFD11AMH21AFSXX
26.3 23.1 50 Class T JJS-50
Table 7-13
230V, three-phase
Model
Input Current (A) Specification of Fuse (600 V
AC
)
Normal Duty Heavy Duty I (A) Normal Duty
VFD1A6MH23ANSXX
VFD1A6MH23ENSXX
2.2 1.9 7.2 Class T JJS-10
VFD2A8MH23ANSXX
VFD2A8MH23ENSXX
3.8 3.4 12.8 Class T JJS-15
VFD5A0MH23ANSXX
VFD5A0MH23ENSXX
6.2 6.0 20.8 Class T JJS-20
VFD5A0MH23ANSNA
VFD5A0MH23ENSNA
6.2 6.0 20.8 Class T JJS-20
VFD7A5MH23ANSXX
VFD7A5MH23ENSXX
9.6 9.0 32 Class T JJS-35
