Chapter 9 Specification
MH300
9-3 460V Models
460V, three-phase
Frame A B
Model VFD_ _ _ _ _ _ _ _ _ _ _A
1A5MH43_ _ _ _
3A0MH43_ _ _ _
ANSA ENSA ANSN
ENSN
ANSA
ENSA
Applicable Motor Output (kW) 0.4 0.75 0.75 0.4 0.75
Applicable Motor Output (HP) 0.5 1 1 0.5 1
*
1
Heavy
Duty
Rated Output Capacity (kVA) 1.1 2.3 2.3 1.1 2.3
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA) 1.4 2.5 2.5 1.4
2.5
Rated Output Current (A) 1.8 3.3 3.3 1.8 3.3
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Current (A)
Heavy Duty 2.1 4.2 4.2 2.1 4.2
Normal Duty 2.5 4.6 4.6 2.5 4.6
Rated Voltage / Frequency Three-phase, 380–480 V
AC
( -15 %– +10 %), 50 / 60 Hz
Operating Voltage Range (V
AC
) 323–528
Frequency Range (Hz) 47–63
Weight (kg) 0.76 0.81 0.77 1.34 1.34
Cooling Method Convective cooling Fan cooling
Ingress Protection Rating IP20 IP40
*3
IP20 IP40
*3
IP20 IP40
*3
IP20
Frame B C D
Model VFD_ _ _ _ _ _ _ _ _SAA
AN EN AF AN EN AF AN EN AF AN EN AF AN EN AF
Applicable Motor Output (kW) 1.5 2.2 3.7 5.5 7.5
Applicable Motor Output (HP) 2 3 5 7.5 10
Rating
*1
Heavy
Duty
Rated Output Capacity (kVA) 3.2 4.3 6.9 9.9 13.3
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA) 3.5 5.0 8.0 11.1
15.1
Rated Output Current (A) 4.6 6.5 10.5 14.5 19.8
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Current (A)
Heavy Duty 5.8 6.1 9.9 14.3 19.3
Normal Duty 6.4 7.2 11.6 16.0 21.8
Rated Voltage / Frequency Three-phase, 380–480 V
AC
( -15 %– +10 %), 50 / 60 Hz
Operating Voltage Range (V
AC
) 323–528
Frequency Range (Hz) 47–63
Weight (kg) 1.05 1.34
1.24 1.84
1.24 1.84
2.07 2.93
2.07 2.93
Cooling Method Fan cooling
EMC Filter Optional
Optional
Optional
Optional
Optional
Ingress Protection Rating IP20
*3
IP20
*3
IP20
*3
IP20
*3
IP20
*3
Table 9-5
NOTE:
1. The
default is heavy duty mode.
2. The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current.
See the derating curve diagram in Section 9-6.
3. The IP rating of the wiring area (main circuit terminals and control terminals, frame A / B / C / D / E / F) and the
vent near the capacitor (frame C / D / E / F) is IP20.
4. When the load is a shock or impact load, use a higher level model.
