Delta MH300 Series User Manual

Chapter 7 Optional AccessoriesMH300
7-6
7-2 Magnetic Contactor / Air Circuit Breaker and Non-Fuse Circuit Breaker
Magnetic Contactor (MC) and Air Circuit Breaker (ACB)
It is recommended the surrounding temperature for MC should be ≥ 60°C and that for ACB should be
≥ 50°C. In the meanwhile, consider temperature derating for components with ON/OFF switch in
accordance with the ambient temperature of the on-site distribution panel.
115V models
Frame Model
Heavy Duty
Output Current (A)
Heavy Duty
Input Current (A)
MC／ACB Selection
(A)
A
VFD1A6MH11ANSAA 1.6 6 11
VFD2A5MH11ANSAA 2.5 9.4 18
C
VFD5A0MH11ANSAA 5 18.8 32
Table 7-5
230V models
Frame Model
Heavy Duty
Output Current (A)
Heavy Duty
Input Current (A)
MC／ACB Selection
(A)
A
VFD1A6MH21ANSAA 1.6 5.1 9
VFD2A8MH21ANSAA 2.8 7.3 13
VFD1A6MH23ANSAA 1.6 1.9 9
VFD2A8MH23ANSAA 2.8 3.4 9
VFD5A0MH23ANSAA 5 6 11
B
VFD5A0MH21ANSAA
VFD5A0MH21AFSAA
5 11.2 18
VFD1A6MH21AFSAA 1.6 5.1 9
VFD2A8MH21AFSAA 2.8 7.3 13
VFD7A5MH23ANSAA 7.5 9 18
C
VFD7A5MH21ANSAA
VFD7A5MH21AFSAA
7.5 16.5 32
VFD11AMH21ANSAA
VFD11AMH21AFSAA
11 24.2 40
VFD11AMH23ANSAA 11 13.2 22
VFD17AMH23ANSAA 17 20.4 32
D
VFD25AMH23ANSAA 25 30 55
E
VFD33AMH23ANSAA 33 39.6 65
VFD49AMH23ANSAA 49 58.8 105
F
VFD65AMH23ANSAA 65 78 130
G
VFD75AMH23ANSAA 75 77 130
VFD90AMH23ANSAA 90 92 150
I
VFD120MH23ANSAA 120 117 185
VFD146MH23ANSAA 146 143 225
Table 7-6
