Chapter 11 Summary of Parameter Settings
MH300
11-40
08 High-function PID Parameters
Pr. Parameter Name Setting Range Default
08-00
Terminal selection of PID
feedback
0: No function
1: Negative PID feedback: by analog input (Pr.03-00)
2: Negative PID feedback: by single-phase pulse input
(MI7), without direction (Pr.10-16)
3: Negative PID feedback: by single -phase pulse input
(MI7), with direction (Pr.10-16)
4: Positive PID feedback: by analog input (Pr.03-00)
5: Positive PID feedback: by single -phase pulse input
(MI7), without direction (Pr.10-16)
6: Positive PID feedback: by single -phase pulse input
(MI7), with direction (Pr.10-16)
7: Negative PID feedback:
by communication protocol
8: Positive PID feedback:
by communication protocol
0
08-01 Proportional gain (P)
0.0
5000.0 (When Pr.08-23 bit1 = 0)
0.00
500.00 (When Pr.08-23 bit1 = 1)
1.0
1.00
08-02 Integral time (I) 0.00100.00 sec.
1.00
08-03 Differential time (D) 0.001.00 sec.
0.00
08-04
Upper limit of integral
control
0.0100.0%
100.0
08-05
PID output command limit
(positive limit)
0.0100.0%
100.0
08-06
PID feedback value by
communication protocol
-200.00
200.00%
0.00
08-07 PID delay time 0.02.5 sec.
0.0
08-08
Feedback signal detection
time
0.03600.0 sec.
0.0
08-09
Feedback signal fault
treatment
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: Warn and operate at last frequency
0
08-10 Sleep level 0.00599.00 Hz / 0.00200.00%
0.00
08-11 Wake-up level 0.00599.00 Hz / 0.00200.00%
0.00
08-12 Sleep delay time 0.06000.0 sec.
0.0
08-13
PID feedback signal error
deviation level
1.050.0%
10.0
08-14
PID feedback signal error
deviation time
0.1300.0 sec.
5.0
08-15
PID feedback signal filter
time
0.1300.0 sec.
5.0
