Delta MH300 Series - 9-1 115 V Models

Chapter 9 Specification
MH300
9-2
9-1 115V Models
115V, single-phase
Frame A C
Model VFD_ _ _ _ _ _ _ _ _SAA
1A6MH11_ _ 2A5MH11_ _
5A0MH11_ _
AN EN AN EN AN EN
Applicable Motor Output (kW) 0.2 0.4 0.75
Applicable Motor Output (HP) 1/4 1/2 1
Output Rating
*
1
Heavy duty
Rated Output Capacity (kVA) 0.6 1.0 1.9
Rated Output Current (A)
1.6
2.5
5.0
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Normal Duty
Rated Output Capacity (kVA) 0.7 1.0
2.1
Rated Output Current (A)
*2
1.8 2.7 5.5
Carrier Frequency (kHz) 2–15 (Default: 4)
Input Rating
Rated Input
Current (A)
Heavy Duty 6.0 9.4 18.8
Normal Duty 6.8 10.1 20.6
Rated Voltage / Frequency Single-phase, 100–120 V
AC
(-15%– +10%), 50 / 60 Hz
Operating Voltage Range (V
AC
) 85–132
Frequency Range (Hz) 47–63
Weight (kg)
0.71
0.76
1.24
Cooling Method Convective cooling Fan cooling
EMC Filter
Optional
Ingress Protection Rating IP20 IP40
*3
IP20 IP40
*3
IP20 IP40
*3
Table 9-1
NOTE:
1. The
default is heavy duty mode.
2. The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current.
See the derating curve diagram in Section 9-6.
3. The IP rating of the wiring area (main circuit terminals and control terminals, frame A / B / C / D / E / F) and the
vent near the capacitor (frame C / D / E / F) is IP20.
4. When the load is a shock or impact load, use a higher level model.
