Delta MH300 Series - 13 Macro (User-defined)

Chapter 12 Description of Parameter SettingsMH300
12.1-13-1
13 Macro (User-defined)
 You can set this parameter during operation.
13-00
Application Selection
Default: 00
Setti
ngs 00: Disabled
01: User-defined parameter
02: Compressor
03: Fan
04: Pump
05: Conveyor
06: Machine tool
07: Packing
08: Textiles
10: Logistics
11: Tension PID function
12: Tension PID and master / auxiliary frequency function
 Note: after you select the macro, some of the default values adjust automatically according to the
application selection.
 Group setting 02: Compressor
The following table lists the compressor application related parameters.
Pr. Parameter Name Settings
00-11 Speed control mode 0 (IMV/F control mode)
00-16 Duty selection 0 (Normal duty)
00-17 Carrier frequency Default setting
00-20
Master frequency command source
(AUTO, REMOTE)
2 (Inputs from external analog)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
00-22 Stop method 0 (Ramp to stop)
00-23 Control of motor direction 1 (Disable reverse)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Motor 1 rated / base frequency Default setting
01-02 Motor 1 rated / base voltage Default setting
01-03 Motor 1 mid-point frequency 1 Default setting
01-04 Motor 1 mid-point voltage 1 Default setting
01-05 Motor 1 mid-point frequency 2 Default setting
01-06 Motor 1 mid-point voltage 2 Default setting
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage Default setting
01-11 Lower frequency limit 20 (Hz)
01-12 Acceleration time 1 20 (s)
