Chapter 12 Description of Parameter SettingsMH300
12.1-13-2
Pr. Parameter Name Settings
01-13 Deceleration time 1 20 (s)
03-00 AVI analog input selection 0 (No function)
03-01 ACI analog input selection 1 (Frequency command)
05-01 Full-load current for induction motor 1 (A) Default setting
05-03 Rated speed for induction motor 1 (rpm) Default setting
05-04 Number of poles for induction motor 1 Default setting
Group setting 03: Fan
The following table lists the fan setting application related parameters.
Pr. Parameter Name Settings
00-11 Speed control mode 0 (IMV/F control mode)
00-16 Duty selection 0 (Normal duty)
00-17 Carrier frequency Default setting
00-20
Master frequency command source
(AUTO, REMOTE)
2 (Inputs from external analog)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
00-22 Stop method 1 (Coast to stop)
00-23 Control of motor direction 1 (Disable reverse)
00-30
Master frequency command source
(HAND, LOCAL)
0 (Digital keypad)
00-31 Operation command source (HAND, LOCAL) 0 (Digital keypad)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Motor 1 rated / base frequency Default setting
01-02 Motor 1 rated / base voltage Default setting
01-03 Motor 1 mid-point frequency 1 Default setting
01-04 Motor 1 mid-point voltage 1 Default setting
01-05 Motor 1 mid-point frequency 2 Default setting
01-06 Motor 1 mid-point voltage 2 Default setting
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage Default setting
01-10 Upper frequency limit 50 (Hz)
01-11 Lower frequency limit 35 (Hz)
01-12 Acceleration time 1 15 (s)
01-13 Deceleration time 1 15 (s)
01-43 V/F curve selection 2 (Second V/F curve)
02-05 Multi-function input command 5 (MI5) 16 (Rotating speed command from ACI)
02-16 Multi-function output 2 (MO1) 11 (Malfunction indication)
02-17 Multi-function output 3 (MO2) 1 (Indication during RUN)
03-00 AVI analog input selection 1 (Frequency command)
